| Prod Model: |
TM1703 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Mode: |
4:3 |
| Brightness: |
400CD/M2 |
| Contrast: |
450:1 |
| Touch Screen: |
4-Wire/5-Wire Touch Panel |
| Touch Interface: |
USB or RS232 |
| Screen Size: |
≤17" |
| Application: |
Surveillance |
| Aspect Ratio: |
4:3 |
| Feature: |
Touch Display |
| Optimum Resolution: |
1024x768 |
| Type: |
TFT |
| Widescreen: |
Not Widescreen |
| Response Time: |
8ms |
| Interface Type: |
VGA |
Product Description
17 Inch TFT LCD Touchscreen VGA Monitor with Metal Bracket
Panel: 17" A+ GRADE Panel
Display Type: 4: 3 /16: 9Ratio
Physical Resolution: 1024X768
4- wires /5-wire resitive touch-screen optional.
Touchscreen Interface: Serial (RS232) or USB optional.
15 pin D-SUB VGA signal input.
SD/USB card reader and TV/AV fucntion is optional.
Built in Speaker.
OSD: Remote control OSD(Voice, Brightness, Contrast)
One VGA input, 2 AV Input, 1 AV Input
Input Video Format: Analog RGB, NTSC/PAL/SCAME(AUTO)
Touchscreen Interface: Serial (RS232) or USB
Operating System: DOS/Window 9X ME, 2K XP Vista NT Windows CE / LINUX / Mac
Power Consumption: <30 W Typ
Working Vplt: 11V-15V
Technical Specification:
*Touch Response Time Serial/USB: 10.4ms
*PowerSupply: 85-265VAC, 50-60Hz
*Pixel Pitch: 0.107 (W) X 0.372(H) mm
*Pixel Response Time Rise + Fall (Typically): 12ms
*Brightness: 400 CD/m2
*Contrast Ratio Typically: 14.58402778
*ViewingAngle Horizontal (left/right): 170° (85° /85° )
* (From Centre, CR>=5) Vertical (up/down): 160° (70° /90° )
*Temperature Range: Operating: -20ºC-60ºC,
*Storage: -30-70ºC
*Relative Humidity Non Condensing: Operating: 10%-90%, Storage 5%-90%
*FM/IR Range: FM-30-88.9 MHz, IR-2.3MHz-2.8MHz
*TV Channel Parameter: VHF-L 48.25~170.00MHz VHF-H 170.00~450.00MHz
Packing
Quantity: 2PCS/CTN
Net Weight: 10KG/CTN
Gross Weight: 12KG/CTN
Carton: 43X42X35CM
