| Prod Model: |
GCOR40GS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation Type: |
Outdoor ,Big Size |
| Technic Advantage: |
Fullband |
| Certificate: |
CE RoHS ISO |
| Work Environment: |
Outdoor ,Big Size |
| Affect: |
Slove Poor Signal Problems |
| Type: |
Signal Repeater |
Product Description
We can make all kinds of frequency:
Such as for indoor single band intelligent repeater: LTE, IDEN, GSM900, GSM1800, GSM1900M, CDMA850, 3G2100 etc
For dualband and tri-band intelligent repeater: GSM900+GSM1800 dualband, GSM900+3G2100M dualband, 900+1800+2100 triband etc.
Outdoor series: Fullband repeater, band selective repeater, frequency selective repeater, frequency shifting repeater etc.
|
Model number |
GCOR40GS |
|
Frequency range |
Uplink: 890-915MHz or Customer Specify |
|
Downlink: 935-960MHz or Customer Specify |
|
Output power |
≥40dBm |
|
Gain |
UL: 85dB |
|
DL: 90dB |
|
Gain adjustable range |
MGC≥30 |
|
Gain adjustable step |
1dB |
|
Selection characteristic |
±0.2MHz <-7dB |
|
±0.4MHz <-25dB |
|
±0.6MHz <-35dB |
|
±1MHz<-50dB |
|
I/O impedance |
50Ω/N connector |
|
VSWR |
1.4:1 |
|
Noise figure |
≤5dB |
|
Spurious emission |
≤-36dBm(9KHz_1GHz) |
|
≤-30dBm(1GHz_12.5GHz) |
|
Intermodulation attenuation |
≥40dBC |
|
Transmission Delay |
≤5μS |
|
Ambient temperature |
-15ºC-55ºC |
|
Ambient humidity |
≤95% (no dew) |
|
Power supply |
AC230V±10% 45-55Hz |
|
Reliability |
To the GB6993-86 standard |
|
Electromagnetic compatibility |
To the ETS300 694-4 standard |
|
Panel display |
LED display Power, uplink, downlink emission, and alarm indicators |
|
Alarm |
Overheat and High VSWR |
