| Prod Model: |
GCOR40GB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Band: |
GSM |
| Frequency: |
UL:890-915MHz Dl:935-960MHz |
| Installation Type: |
Outdoor ,Big Size |
| Technic Advantage: |
Fullband |
| Certificate: |
CE RoHS ISO |
| Type: |
Signal Repeater |
Product Description
We can make all kinds of frequency:
Such as for indoor single band intelligent repeater: LTE, IDEN, GSM900, GSM1800, GSM1900M, CDMA850, 3G2100 etc
For dualband and tri-band intelligent repeater: GSM900+GSM1800 dualband, GSM900+3G2100M dualband, 900+1800+2100 triband etc.
Outdoor series: Fullband repeater, band selective repeater, frequency selective repeater, frequency shifting repeater etc.
| Model number | GCOR40GB |
| Frequency range | 890-915MHz or Customer Specify |
| 935-960MHz or Customer Specify |
| Output power | 40dBm |
| Gain | UL: 85dB |
| DL: 90dB |
| Gain adjustable range | MGC≥30 |
| Gain adjustable step | 1 dB |
| Gain control precision | ±1.5 dB |
| Pass band ripple | ≤±1.5dB |
| Noise figure | ≤5dB |
| I/O return loss | ≤1.4 |
| Transmission Delay | ≤1.5μS |
| I/O impedance | 50Ω/N connector |
| Spurious emission | Carrier frequency Pass Band | <-42dBc/30KHz(Δf≥750KHz)
<-54dBc/30KHz(Δf≥1.98MHz) |
| Pass BandΔf≥2.5MHz | ≤-22dBm/30KHz |
| Out-bandΔf≥2.5MHz | ≤-36dBm/1KHz(9KHz_150KHz)
≤-36dBm/10KHz(150KHz_30MGHz)
≤-36dBm/100KHz(30MHz_1GGHz)
≤-30dBm/1MHz(1GHz_12.5GHz)
≤-67dBm/100KHz(806MHz_821MHz)
≤-67dBm/100KHz(885MHz_915MHz)
≤-67dBm/100KHz(930MHz_960MHz)
≤-67dBm/100KHz(1.8GHz_1.93GHz)
≤-67dBm/100KHz(3.4GHz_3.53GHz) |
| Intermodulation attenuation | In work band | ≤-15dBm/30KHz |
| Out work bandΔf≥2.5MHz | ≤-36dBm/30KHz(9KHz_1GHz) |
| ≤-30dBm/30KHz(1GHz_12.5GHz) |
| Guard band rejection | ≤40dB or -13dBm/30KHz Δf≥2.5MHz |
| ≤60dB or -33dBm/30KHz Δf≥10MHz |
| Ambient temperature | -15ºC-55ºC |
| Ambient humidity | ≤95% |
| Power supply | AC230V±10% 45-55Hz |
| Reliability | To the GB6993-86 standard |
| Electromagnetic compatibility | To the ETS300 694-4 standard |
| Panel display | LED display, Power, uplink, downlink emission, and alarm indicators |
Gainer International (China) Limited is a professional enterprise which specialized in wireless communication products, customer electronics products. We are highly developing enterprise, with CE certificate and GB/T19001-2008 /ISO 9001: 2008. We spare no effort to provide good products and service for customers all over the world.
We mainly produce signal repeater, booster of GSM, CDMA, DCS, WCDMA, IDEN, LTE CDMA450M, also other correlative products. We manufacture products by our own R&D team which was formed by experienced exports in related fields. Our design and manufacture can follow customers' special requirements.
We dedicate to provide the most satisfactory services for our customer. We aim to provide more competitive products and meet the needs of high-speed developing market.
Our products have been sold to the worldwide markets like USA, Italy, the Netherlands, New Zealand, France, Switzerland, Ireland, Russian, Spain, Poland, UK, South Africa, Brazil, Mexico, Saudi Arabia, Jordan, Indonesia, Malaysia, India, UAE, Iceland, Australia, Czech Republic, Kyrgystan, and more.
We ensure to offer the best quality and the lowest price to help you to develop your market, Hope to built up long term business relation with you.
Cooperate with Gainer International, you will be the gainer of the world, we are waiting for you!
