| Prod Model: |
TM121SDS01 LCD Display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Graphic Design |
| Aspect Ratio: |
4:3 |
| Feature: |
LED Backlight Display |
| Type: |
TFT |
| Widescreen: |
Widescreen |
| Response Time: |
20ms |
| 3D: |
Not 3D |
| Screen Size: |
12.1inch |
| Optimum Resolution: |
800*600 |
| Interface Type: |
Lvds |
Product Description
LCD screen size 12.1 inches
Point resolution 800RGB) * 600 (SVGA)
Pixel density 82PPI
RGB vertical stripe pixel array
The aspect ratio of 4: 3 ( width: height )
Dot pitch 0.1025 * 0.3075mm ( horizontal * vertical )
Pixel pitch 0.3075 * 0.3075mm ( horizontal * vertical )
Panel Weight TBD
Matte surface treatment
Display area 246.0 * 184.5mm ( horizontal * vertical )
Viewable area 249.05 * 188.3mm ( horizontal * vertical )
Dimensions 279.0 * 209.0 mm ( horizontal * vertical )
Dimensions 9.0 (Typ.) Mm ( thickness )
No touchscreen
Display Mode TN, often white display , transmissive
LCD Brightness 450cd / m
Contrast 700: (. Typ) 1 ( transmission )
Display Color 262K / 16.2M
Gamut 55% NTSC (CIE1931)
Response Time 10/25 (Typ.) (Tr / Td) (ms)
Viewing Angle 80/80/65/75 (Typ.) (CR≥10) ( left / right / up / down )
Look into the best perspective on the 6 o'clock
White color X: 0.313; Y: 0.329
White field variation 1.25 / 1.33 (Typ. / Max.) (9 points)
Tianma 12.1-inch LCD screen TM121SDS01 industrial lighting system
Position side- light lamp
Light type WLED
Source life 50K (Min.) ( H )
Single lamp voltage 25.0 / 33.0V (Min. / Max.)
Single- lamp current 80mA (Typ.)
Interface Type Terminal
LED backlight driver circuit containing
Backlight circuit 12.0V (Typ.) ( Input voltage )
Tianma 12.1-inch Industrial LCD TM121SDS01 signal interface
LVDS signal categories
Signal subcategories LVDS (1 ch, 6/8-bit)
Panel voltage 3.3V (Typ.)
Panel Current 325mA (Max.)
Number of interfaces 1pcs
Interface pin count 20pins
Yaosheng provide total solutions for LCD panels and modules. We support both monochrome STNs and full-color TFT LCDs. We provide full customized monochrome STN, and semi-customized TFT modules. We are supplying a wide variety of LCD modules to meet the ever-growing demands.
Yaosheng Solutions get strong support from Tianma, Truly, and Innolux, we provide flexible support to our customers, fast delivery, flexible MOQ, and competitive cost.
Please check the following website to find the products supported by us.
Our products include LCD panels of TN, STN, FSTN; LCMs with COG, COB, TAB; And TFT LCD modules.
Custom LCD Panels: Segment, icon, chracter, and mixed
Custom / Standard Character: 16X1, 16X2, 16X4, 20X2, 20X4, 24X2, 40X2, 40X4
Custom / Standard Graphic: 128X64, 128X128, 160X128, X160X160, 240X128, 240X64, 320X240
Semi-custom / Standard TFT Modules: 2.8", 3.5", 4.3", 4.7", 5.0", 7.0", 10.4"
All of our displays are RoHS compliant, which have been used in wide range of applications: Communication, Medical, Instrumentation, Metering, and Industrial applications.
We endeavour to serve our customers with Quality Products, Competitive Cost, Excelled Service, and Fast Delivery.
