| Prod Model: |
UW-1032 |
| Markets: |
South America,Southeast Asia,Africa,Mid East |
| Style: |
Handheld Microphone |
| Application: |
Meeting |
| Signal Transmission: |
Wireless |
| Directivity: |
Omni-direction |
| Sound Channel: |
Stereo |
| Transducer Principle: |
Electrodynamic Microphone |
| Sound Field Force: |
Combined Type |
| Connector(',s): |
XLR 3 Pin |
| Wireless Technology: |
UHF |
| Output Impedance: |
50-1000Ω |
Product Description
Receiver parameter:
Frequency range: 740-820MHz
Oscillation mode :phase locked loop synthesis(PLL )
Modulation mode:FM
The maximum frequency deviation: ±50KHz
Sensitivity:18dBuV( can be adjusted)
SNR:>89dB
Frequency response:60Hz-15KHz(±3dB)
Audio output:0-300mV/600Ω
Balance output:0-300mV/600Ω
Dynamic range:≥105dB
Working voltage: DC 12V
Working current:50mA
Working tempreture:-10ºCto +40ºC
Launcher technology parameter:
Frequency range: 740-820MHz
Emission power:10mW
Frequency stability:≤ ±0.005%
Modulation mode:FM
The maximum frequency deviation: ±50KHz
Frequency selection :infra-red matching the frequency confirm the launcher working frequency
Working power:DC4.5V(1.5V AA*3)
Working current:≤100mA
Working tempreture:-10ºCto+40ºC
Lipoor electronic sound equipment factory which it is a modernizatinal and technological enterprise entablised in 2005 it combines with scientific research, production and sales. Professional production and management: Anti--phone interference multi-functional digital conference system, vote system, simultaneous interpretation system, control matrix system, profession conference microphone, profession wireless microphone and meeting peripherals such series product. We insist in the management idea and development strategy of "inovation for development, quality for living", with powerful R&D groups, strict quality control and good quality customer services, inovatitive enterprise for standing on the top of the industry all the time. We sincerely would like to cooperate with the customer, to face the tempestuous waves of the business, to create the futher together. With the continues develpoment of social progress and social scientific technology economic, the demand of people for meeting equipment are higher and higher, only the complete function, reliable quality elegent appearance can be popular by the people. The product of our company have been for many years in the sales of similar products in the forefront of China.
