| Prod Model: |
BU-3880 |
| Markets: |
North America,South America,Africa,Oceania |
| Frequency Range: |
UHF 500-900MHz |
| Channels: |
Eight Channel |
| Size: |
480*220*88mm |
| Type: |
Tabletop Microphone |
| Monitor: |
Yes |
| Length Of Gooseneck: |
435mm |
| Using Distance: |
480*220*88mm |
| Signal Transmission: |
Wireless |
| Application: |
Meeting |
Product Description
1. Eight channels receiver.
2. Oscillation: PLL synthesized.
3. IR automatic frequency technology is adopted. Each channel has 32 optional frequencies, stepping up/down by 0.5MHz.
4. Carrier frequency: UHF 500MHz-900MHz.
5.5 sets can be used at the same time. That means 5 receivers and 40 transmitters can be used at the same meeting.
6. LCD screens on the receiver will display working channel, working frequency and signal level. Each screen will display informations of 2 channels.
LCD screen on the transmitter will display working channel, working frequency and battery storage.
7. Using 2 rubber antenna for receiving brings a better appearance and anti-interference ability.
8. There are 2 blanced output and 1 unblanced output in the back-panel, suitable for linking up with other audio equipments.
9. Microphone power consumption is 80mA. With two 1.5V battery power supply, it can work constantly for 8 hours.
10. Light ring on the microphone head will display working status. (ON-white, OFF-blue)
11. Working distance: Open environment: 80-100 meter. Complicated environment: 50-80meter.
12. It's suitable for various kinds of conference and performance occasion.
Parameter:
Channel number: 8
Oscillation Mode: PLL syntheized
Modulation Mode: FM
Carrier Frequency Range: UHF 500~900MHz
Frequency Stability: +0.001%
Max. Deviation Range: +50kHz
S/N Ratio: > 105dB
T. H. D: < 0.5%@1kHz
Sensitivity: 1.2/UV@S/N=12dB
Power Supply: DC 12~17V
Audio Output: Independent: 0-400mV
Mixed: 0-300mV
