| Prod Model: |
TK-01-17 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
15"--100" |
| Brand: |
Touchkit |
| Screen Type: |
Infrared |
| Touch: |
Optional Two Touch |
Product Description
Infrared Touch Screen
Specification
Transparency > 92%, Up to 100%
Touch Resolution Interpolated 4096 X 4096
Scanning Speed 50scans/s
Minimum Touch object >5mm
Response Speed < 16ms
Touch Intensity Over 60, 000, 000 Single Point Touch
Vandal-Proof Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break
Electricity
Operating Voltage DC 5V +/-5%
Power Supply Expernal power supply
Power < 2W
EMI CE, FCC
Noises No Noises
Operation System Windows2000\XP\2003\CE\Linux
Communication USB / RS-232
Environmental
Temperature Operating: -20° C to 50° C
Storage: -50° C to 80° C
Humidity Operating: 0 to 85%
Storage: 0 to 95%
Altitude 3, 000m
Direct Light No Disturbing
Drift Maintenance free
Life Time 7-year
Applications:
Gaming machine
Indoor and outdoor Kiosks
ATMs
Industrial control
Gas pump
In-vehicle and transportation
Medical equipment
Any highly demanding applications
Guangzhou yulian electronic technology Co., Ltd. is the mainly professional manufacturer in producing mapletouch POS terminals, industrial control systems and multifunction inquiry touch kiosks in China. We have been an innovative and creative force in the development and manufacturing of high quality, high performance systems since 2000. Now our products have obtained the certificates of ISO9001: 2000, CE, FCC, CCC, CB, ROSH and widely applied to many fields.
