| Prod Model: |
SMART82 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Channels No: |
6 |
| Frequency Response: |
10Hz-80kHz |
| MP3 Play: |
Yes |
| Fx Processor: |
99 DSP |
| Dynamic Range: |
128.5 dB |
| Gain Range: |
60dB |
| Phantom Power: |
48V |
| Noise: |
<95dB |
| Hi-Fi: |
Not Hi-Fi |
| Operation Mode: |
Wire / Remote Control |
| Application: |
Commercial |
| Certification: |
CE |
| THD: |
<0.005% |
| Speaker System: |
Professional Preformence |
| Speaker Material: |
Birch Plywood |
| Monitor: |
Professional Preformence |
Product Description
Smart62 6 channels USB with MP3 play audio DJ mixer
Product Description:
This mini audio mixer is the new design of skytone audio, providing 4-12channels for options, which has MP3 play, 99 DSP effectors, USB connector and 48V Phantom for condeser microphone. Mini with fashion design.
Features:
Ultra-thin fashionable palm design
Ultra-high dynamic & low-noise
High quality Mic preamp
Ultra-wide 60dB gain range
128.5 dB dynamic range
+22 dBu line input processing
Distortion lower than 0.0007%(20hz - 50khz)
48V Phantom for condenser microphone
Radio frequency interference resistance
High dynamic circuit input + 4/-10 operational control
Mono channel 3-band equalizer (low; middle; high) design
2 Aux Sends, 1 Stereo Return, mute LED prompt for overload
99 types of DSP effect
CD/mobile phone Multi-input sources matrix with separate level controls
High resolution 6 LED lights for stereo
High density dust-proof , sturdy and durable chassis
Specifications:
Model | SMART62 |
| Mono/stereo input channels | 4/2 |
| Mp3 Play | Yes |
| Mic Preamps | 6 |
| Phantom Power | Yes |
| Mono channel EQ | 3-band |
| Stereo channel EQ | 3-band |
| Aux Sends channel | 2 |
| FX Returns | 1 |
| FX Processor | 99 DSP |
| Subgroups | 2 |
| Mic Input (Maximum levels) | 30dBu |
| Line Input (Maximum levels) | 21dBu |
| All other lnput (Maximum levels) | 22 dBu |
| Mixer Rated Output (Main outs) | +4dBu |
| Mixer Rated Output (All other outputs) | +4 dBu |
| Mixer Rated Output (Maximum output) | 22 dBu |
| Frequency response (Mic input to main output ) | +0,-1 dB,<10Hz to 80kHz |
| +0,-3 dB,<10Hz to 120kHz |
| Connection Impedance (Mic inputs): | 4.7ohms |
| Connection Impedance (Line Inputs) | >10k ohms |
|
| Connection Impedance (Outputs) | >120 ohms |
|
| EQ(each band): | ±15dB |
| Mono channel EQ: ( High ) | 12KHz |
| Mono channel EQ : ( Mid ) | 2.5kHz |
| Mono channel EQ : ( Low ) | 80Hz |
| Stereo channel EQ: ( High ) | 12KHz |
| Stereo channel EQ :( Mid ) | 2.5kHz |
| Stereo channel EQ: ( Low ) | 80Hz |
