| Prod Model: |
MA series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Tdspro. |
| Product Type: |
Professional Amplifier |
| Place Of Orignal: |
Guangzhou China |
| Product Warranty: |
4 Years |
| Function: |
Amplifier Combined |
| Tube Type: |
Transistor Amplifier |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Output Number: |
4 |
| Used For: |
Professional |
| Conductive Mode: |
B |
| Usage: |
KTV System |
| Sound Channel: |
2 |
Product Description
Features
1. Adopt Motorola & Thosiba transistor.
2. Good quality transformer.
3. High cost performance amplifier.
4. 4 years product warranty.
|
SPECIFICATION |
MA-450 |
MA-600 |
MA-800 |
MA-1000 |
MA-1300 |
|
8ohm Stereo output (RMS) |
2 x 450W |
2 x 600W |
2 x 800W |
2 x 1000W |
2 x 1300W |
|
4ohm Stereo output (RMS) |
2 x 700W |
2 x 960W |
2 x 1300W |
2 x 1500W |
2 x 1800W |
|
2ohm Stereo output (RMS) |
2 x 1000W |
2 x 1400W |
2 x 1800W |
2 x 2000W |
2 x 2400W |
|
8ohm Bridge output |
1400W |
1920W |
2600W |
3000W |
3600W |
|
4ohm Bridge output |
2000W |
2800W |
3600W |
4000W |
4800W |
|
Frequency Response |
20Hz -- 20KHz +0/-0.3dB |
|
THD+N |
< 0.05% @ 4ohm/1KHz |
|
S/N Ratio |
>110dB |
>105dB |
|
Slew Rate |
60V/US |
|
Damping Factor |
800:1 |
|
Cross Talk |
>800 @ 8ohm / 1KHz |
|
Input Impedance |
>20KHz(balance)/ >10KHz(unbalance) |
|
Protect |
DC, SHORT CIRCUIT. OVERHEAT, SOFTSTART |
|
Dimension (W x H x D) |
89 x 483 x 472mm |
123 x 483 x 472mm |
|
Gross Weight |
19Kg |
21Kg |
25Kg |
29Kg |
31Kg |
Guangzhou TDS PRO Audio Factory specialize in developing & manufacture PRO audio products.
From the establishment of our factory we always focus our attention on developing PRO audio products.We trust a good product must need very careful process in developing and manufacture.Thanks to our senior engineers and the sophisticated staff, we can offer the products which customers need.At the same time, we use the technical way to guarantee the products quality.We use CAD for cabinet design work, CNC machine to make the speaker cabinet, DASS & LMS for testing of loudspeaker, crossover checking and phase checking equipment etc.All those work help us to keep the same product quality.
In all business, product is important.But the related service is more important.In order to offer ideal service, we have professional staff for products checking, transportation arranging and also we have engineers who can go abroad to do technical support and after sales service.Our philosophy is customer to be first.And we also trust better service will help both customer and us.Through good service we can keep long and steady relation with our customers.
Meet right sound, Meet right OEM partner, Meet right us!
