| Prod Model: |
SA 600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output Power: |
650w(8 Ohm) |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Function: |
Post Amplifier |
| Tube Type: |
Tube Amplifier |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
AB |
| Sound Channel: |
2.0 |
Product Description
Power amplifier SA300
1. 650W(8ohm)
2. 2U rack, 20Hz~20KHz
3. Suitable for show place
4. Duly delivery
SA series amplifier has reliability quality, huge output power, best tone. Suitable for gymnasium, band, showplace, dancery and disco.
|
Model |
SA200 |
SA300 |
SA500 |
SA600 |
|
Stereo (8ohm) |
250W |
350W |
500W |
650W |
|
Stereo (4ohm) |
400W |
550W |
800W |
950W |
|
Stereo (2ohm) |
600W |
800W |
900W |
1150W |
|
BTL |
650W |
900W |
1250W |
1650W |
|
Frequency Response |
20Hz ~ 20KHz |
20Hz ~ 20KHz |
20Hz ~ 20KHz |
20Hz ~ 20KHz |
|
THD |
Less than 0.05% |
Less than 0.05% |
Less than 0.05% |
Less than 0.05% |
|
IMD |
Less than 0.05% |
Less than 0.05% |
Less than 0.05% |
Less than 0.05% |
|
Slew Rate |
100V/us |
100V/us |
100V/us |
100V/us |
|
Input Impedance |
5Kohm |
5Kohm |
5Kohm |
5Kohm |
|
Signal Noise Ratio |
More than 105dB |
More than 105dB |
More than 105dB |
More than 105dB |
|
Input Sensitivity |
0.775V |
0.775V |
0.775V |
0.775V |
|
Height |
2U |
2U |
2U |
2U |
|
Power Supply |
AC 110-240V at 50-60Hz |
|
Gross Weight |
24.00KGS |
26.00KGS |
28.00KGS |
30.50KGS |
|
Dimensions |
54.60x58.00x19.00cm |
NAPHON MUSIC, based in Shenzhen, is a company specialized in the design and production of quality professional audio equipments. Its package of products are widely used in music venues, theatres, houses of worship, sporting events and much more.
NAPHON MUSIC has a major commitment to produce the most accurate & reliable product available. It maintains an extensive research and development division which is constantly looking for ways to improve the performance, value and reliability of products, introduced the Surface Mounting Technology, proudly launched its new MC series of DSP Mixers and SA series of Amplifiers. With a stringent quality control in production, it can arrive at an ever higher standard of quality for full range of products. NAPHON MUSIC had got ISO9001: 2000 International Standard Approval and CE approval.
NAPHON MUSIC always focus on tomorrow, embracing severe construction standards and the on-going aim to provide the best sound and most outstanding customer service you've ever experienced.
