| Prod Model: |
P6 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Production Time: |
7 Days |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
16mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
Static Scan |
| Display Type: |
LED Video Display |
| Application: |
Stage Performance |
| Certification: |
ETL |
Product Description
P6 SMD indoor Led display screen/led screen/Led display
LED Board Sign/Outdoor Full Color LED Display for Advertising on Wall (P8, P10, P16, Promotion)
Product Description
Product features:Ideally for any indoor display applications,from concerts to stage performances,3-in-1 SMD displays are the perfect LED rental display solution for attracting viewers'attention,adding significant value to any indoor event.The SMD lamps bring exceptional color and wide viewing angles.Excellent images and cost-saving convenience make the SMD display the best choice for any number of indoor applications .Moreover ,the ultra resolution LED panels deliver unsurpassed image quality,while the fan-less designs run absolutely silently,invariably a key requirement for indoor applications .
1 The indoor series from Retop boasts wider viewing angles ,and the enhanced surface,for an exceptional picture quality in any indoor setting .
2 With a light output more than 1,200 nits and native 16-bit color processing ,it is sure to deliver the pinnacle of image quality in all circumstances .
3 The module desigh and slim casing make installation simple ,featured in seamless and light weight .
LAMP | LED Type | SMD 3-in-1 |
| Wave length | R: 620 nm |
| G: 524 nm |
| B: 468 nm |
| BOARD | Pixel configuration | 1R1G1B |
| LED driving method | 1/4 dynamic scan |
| Pixels | 16 | * | 16 | (W*H) |
| Pixel pitch | 12 | mm |
| Led board size | 192 | mm | * | 192 | mm | * | 16 | mm | (W*H*D) |
| MODULE | Led boards | 4 | * | 4 | (W*H) |
| Pixels | 64 | * | 64 | (W*H) |
| Module area | 0.59 | m 2 |
| Module size | 768 | mm | * | 768 | mm |
| * | 166 | mm | (W*H*D) |
| Net weight | 30 | kg | (aluminum) | / | 35 | kg | (ferrum) |
| Power | AC220/110 ± 10%, 47~63Hz |
| Water proof | N/A |
| Serviceability | Rear service |
| DISPLAY | Max. power consumption | R | ≤ | 640 | W/m 2 | N | ≤ | 800 | W/m 2 | C | ≤ | 670 | W/m 2 |
| Avg. power consumption | ≤ | 224 | W/m 2 | ≤ | 280 | W/m 2 | ≤ | 235 | W/m 2 |
| Max. current (208V 60Hz) | ≤ | 3.42 | A/m 2 | ≤ | 4.27 | A/m 2 | ≤ | 3.58 | A/m 2 |
| Hor. viewing angle(min 50% brightness) | 140° |
| Vert. viewing angle(min 50% brightness) | 140° |
| Brightness | ≥1200 cd/m 2 |
| Pixel density | 6944 | /m 2 |
| Power factor | >0.9 |
| Certifications | UL,CE,ETL,ROSH,CCC |
| Contrast ratio | 2000:1 |
| Operating temperature | -20ºC to +60ºC |
| Operating humidity | 20% to 90% |
| Lifetime (50% brightness) | 100,000 hours |
| Processing | 16 bit |
| Colors | 281 trillion |
| Refresh rate | ≥2400 Hz |
| Frame rate | 60 fps |
| Brightness level | Manual 100 levels,automatically 16 levels. |
Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.
Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.
Quality is the most important theme for Myled and welcome to contact, and visit our company.
We hold the truth that better quality, better price and better sales services are our company culture.
