Gxf Series Mixed-Flow Fans

Gxf Series Mixed-Flow Fans
Price: US $ 100/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: GXF
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 4-13
Voltage: 110V/230V/380-450V
Certification: CE
Electric Current Type: AC
Mounting: Duct Fan
Blade Material: Cast Iron

Product Description

Product Description:
GXF series mixed-flow fans have the advantages such as high efficiency,low-noise,compact structure,easy-installation,reliable operation etc,they are widely used for air ventilation systems in the mining and industrial enterprises.

























Fan Number Rotation Speed Volume Flow Total Pressure Power Noise Weight
N o rpm m 3 /h Pa KW dB(A) Kg
4A 1450 4364-3283 185-266 0.37 68 46
4.5A 1450 4602-3462 235-337 0.55 70 56
5A 1450 7799-5808 290-416 1.1 75 75
5.5A 1450 8736-6572 251-403 1.5 76 85
6A 1450 11342-8533 293-360 1.5 76 95
7A 960 19186-13952 372-457 3 78 156
8A 960 23116-17393 251-383 3 82 200
9A 960 36215-26994 230-385 4 84 235
10A 960 44176-36743 247-382 5.5 85 270
11A 960 48797-43644 282-366 7.5 86 350
12A 720 58513-44022 333-485 11 86 460
13A 720 74393-55971 383-593 15 87 615
Fan Number Rotation Speed Volume Flow Total Pressure Power Noise Weight
N o rpm m 3 /h Pa KW dB(A) Kg
4B 1450 5191-3943 337-403 0.75 70 52
4.5B 1450 5889-4474 426-510 1.1 73 65
5B 1450 7409-5919 425-549 1.5 76 80
5.5B 1450 8460-6758 514-664 2.2 78 90
6B 1450 10466-7951 391-597 2.2 75 117
6.5B 960 13192-10022 390-467 2.2 75 125
7B 960 18419-13994 452-541 4 79 164
8B 960 24165-18359 391-596 5.5 79 265
9B 720 27572-21611 375-573 5.5 81 285
10B 720 37823-29645 453-584 7.5 83 325
11B 720 54526-35604 548-707 11 84 425
12B 720 28975-46224 652-841 18.5 86 575
13B 720 66218-51900 765-987 22 88 640
14B 720 80489-67496 657-951 22 89 695

SAYI electric Co., Ltd is located at east sea, and the traffic is very convenient. It's near to 104 national high way and the exit of yongtaiwen speedway. It's about 18km from taizhou airport, Daxi town is a very important town in the southern industry of taizhou city as the enviroment is graceful and the hills are beautiful as well as the putuo mountain in the east.

The site area of our company is 30, 000m2, while the building area is 50, 000m2. The registered capital of our company is USD12, 000, 000, the capital asserts is 50 million and the current assets is 60million. We have more than 500 staffs, which of them are over 80 of advanced, secondary and primary professional technical staffs. Our company is member of fan guild of China, which professional research, produce, sale and service the industrial fan series products.

The Max, capital of SAYI is the"person with ability"and "famous brand name". Our company has abundant technical force and topping testing center, R and D center, mould process center, modem standard plant and the advanced peoduction line and large equipemtn(including painting production line, electrophoresis line, numerical control plasma, fast assemble line, utomatic and fast punch and automatic winding equipment).

SAYI is based on the advanced of science and technology and the unique management concept, carrying our the quality management system of ISO 9001: 2000 widely, and the products carrying out the IEC standard, so the qualityis improving that our company is enlarging ceaselessly.

In the recently few years, we nearly cooperate with scientific research branches and colleges. We have been provided with ability of design testing set., Moreover we mainly based on the industrial fan, and our sales network is all over the wolrd.

Welcome all the customers of the world to do business with us, we are looking forward to create the resplendence with you.
