| Prod Model: |
TJSUN |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: |
Compact Type |
| Pressure: |
Unpressurized |
| Interior Material: |
Stainless Steel |
| Collector Components: |
Glass Vacuum Tube |
| Composition: |
Tank Insulation |
| Max. Capacity: |
500L |
| Certification: |
500L |
Product Description
1) Inner water tank shell all are made of SUS304-2B food grade stainless steel plates, welded by argon arc.
Outer tank and frames are made of color steel or zinc-coated material. Water is pure and drinkable.
Inner tank thickness is 0.4mm, the highest thickness for SP-R direct insert lower pressure can be 0.8mm.
2) Heat insulation of water tanks adopts polyurethane foam and the thickness is 55mm
3) Silicon rings to connect and seal them
4) The tubes and supports are adjustable. The power bearing is average and can assure the vacuum tubes to use for a long time
5) Whole glass vacuum tubes adopt super hard borax and silica glass
6) Absorption rate: ≥ 93%, thermal radiation rate: ≤ 6%
7) It resists 25mm hail and the using life can last 15 years
8) Temperature when exposed to sun without water: 250, 2.5 hours to boiling point if using single tube
9) If you use electrical appliances to aid heating and to switch off the power supple before bathing
10) Please test the water temperature before using, in order to avoid scalding.
Question 1: Which parts are consist of a solar water heater system?
Answer:Mian parts are:Insulation Tank,Solar Collector,Mounting Frame
Accessories: Safety valve,PT valve,male connectors
Selected supporting: Electrical Heater,5L Feeder Tank,Solar Controller
Question 2: What's the difference between with and without 5L feeder tank(water cylinder)?
Answer: The feeder tank is installed in top of main tank,there's float valve inside,and could adjust the water feeding and stop feeding,is a quite good design.
Question 3:If the customers are not familiar with installation,how to do it?
Answer: Don't worry about this.There's Installation Video,also Instruction Manual to show the process of installing,very clear for every step.
Question 4:Which other services your factory can do?
Answer:TJSUN is not only a solar water heater manufacturer,but also a technology supporter for energy savings.The factory had installed lots of projects for different areas,accumulated much experience.Whole type products can meet different requires,cold or warm conditions,high or cheap price.
Question 5: What's the warranty and after-sale services?
Answer:The main parts of non-pressure solar products are have a 5 years warranty,the design life is more than 15years.
The accessories parts are from 2-3years warranty.
For after sale service,if it's caused by quality problem,TJSUN agrees to replace the broken part in free charge.
If technology support for project,TJSUN engineer can come for technical guidance.
| Integrative Non Pressurized Solar Water Heater TJ-G Series |
| Model | Vacuum Tube | Collecting
area(m2) | Tank | Frame Material | Material of inner and outer tank | Heat insulating layer | For How many people use | Dimension(mm) |
| TJ-G series | Dia/Len(mm) | Quantity(pcs) | Dia outer/inner (mm) | Volume(L) |
| TJ-G2-12 | 58/1800 | 12 | 1.48 | 480/380 | 100 | Galvanized steel plate with plastic spraying | Inner tank: stainless steel SUS304-2B Outer tank: color steel plate | 50mm thickness polyurethane foam | 2 | 1130*1740*1890 |
| TJ-G2-16 | 58/1800 | 16 | 1.98 | 480/380 | 130 | 3 | 1430*1740*1890 |
| TJ-G2-18 | 58/1800 | 18 | 2.23 | 480/380 | 150 | 3 | 1580*1740*1890 |
| TJ-G2-20 | 58/1800 | 20 | 2.48 | 480/380 | 160 | 3,4 | 1730*1740*1890 |
| TJ-G2-24 | 58/1800 | 24 | 2.98 | 480/380 | 200 | 4 | 2030*1740*1890 |
| TJ-G2-30 | 58/1800 | 30 | 3.73 | 480/380 | 240 | 5 | 2480*1740*1890 |
| TJ-G2-32 | 58/1800 | 32 | 3.98 | 480/380 | 260 | 6 | 2630*1740*1890
|
