Flexible LED Display P10mm
| Price: |
US $ 1/Square Meter |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Square Meter |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
FLDP10OS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
10mm |
| Display Function: |
Video Display |
| Scanning Mode: |
1/4 Scan |
| Certification: |
CE |
| Pixel Density: |
10000 dot / m² |
| Average Power Consumption: |
300W / m² |
Product Description
Flexible led display P10mm, flexible curtain led display, flexible led video wall
1. High quality and big size LED chip with high brightness and good color uniformity
2. New and Unique PCB design with best heat dissipation, good stable capability
3. High contrast ratio 4000: 1, clear and stable pictures without distortion and disturbance
4. Light weight, ultra slim panel, buckle connecting design, fast to assemble and disassemble
5. Modular design, can realize joint any size LED display randomly
6. Each color processing 16bit, 281trillion colors vividly displaying
7. Waterproof IP65 protection, can be used both outdoor and indoor
8. With video processor together can support AV, S-Video, VGA, DVI, HDMI, SDI, DP
Service:
1. We provide LED display connection and installation instruction or graph for you
2. Welcome your engineer come and accept training in our workshop, training time is 3 work days
3. We can assign our engineer to your local installation site for display installation guidance, But you need to be responsible engineer tickets, local transportation together room and board cost.
|
Model |
FLDP10 |
|
Pixel pitch |
10mm |
|
Pixel composition |
SMD 3 in one LED |
|
Pixel Density per SQM |
10000pixels/SQM |
|
LED |
SMD3535 |
|
Brightness |
>2000CD/SQM |
|
Scan Mode |
1/8 |
|
Drive Mode |
Constant Current |
|
Panel Dimension |
1280x320(MM) |
|
Panel Dimension |
50.4x12.6(Inch) |
|
Panel Material |
Aluminum |
|
Weight |
5KG/pcs |
|
Module Dimension |
320x80(MM) |
|
Module Dimension |
12.6x3.15(Inch) |
|
Pixel Matrix per Module |
32x8pixels |
|
Pixel Matrix per Panel |
128x32pixels |
|
Refresh Rate |
≥3000HZ |
|
Contrast ratio |
4000:1 |
|
Gray Scale per Color |
65536Level |
|
Colors |
281trillion |
|
Viewing Angle(H/V) |
140/120(deg) |
|
IP Rate (Front /Rear) |
IP65 |
|
Power Consumption ( Max /Avg) |
450/150(W/SQM) |
|
Input Voltage(AC) |
110V-240V,50/60HZ |
|
Operating Temperature |
-20deg---+60deg |
|
Operating Humidity |
10%_95%RH |
|
Source Compatibility (with Video Processor) |
AV, S-Video, VGA, DVI, HDMI, SDI, DP |
