Dsf Series Cooking Oil Purifier
| Price: |
US $ 1800/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
DSF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Supply: |
380V,50Hz(Optional) |
| Color: |
Optional |
| Acid Value: |
<0.05 Mkoh/G |
| Working Noise: |
<65dB |
| Operation Training: |
Supply for Free |
| Deliver Time: |
10days |
Product Description
Application
Filtering cooking oil has many benefits, from extending the life of the oil to increasing the
food quality. Our DSF cooking oil purifier can greatly increase the usable life of your
cooking oil by removing water, impurities, odor, acidity, color etc, instead of simply
replacing the oil. This system will give you more use out of your restaurant's cooking oil.
It is safer for employees, it lasts longer, and it removes the unsightly waste that normally
comes with frying oil.
DSF cooking oil purifier can save you up to 50% on your oil purchasing, reduce your
storage needs, reduce your oil disposal needs, increase the taste and quality of your
foods and provide your customers healthier deep fried foods.
Features
1.Advance vacuum dehydration system, pressure filters, oil water separator and high
precision filters. The water content less than 5 ppm and filtering precision less than 1
micron
2.Stainless steel coarse filters, anti-corrosion and anti corrupt. large capacity of holding
particles, good mechanical performance, long lifetime.
3.Using the most advanced atomizing separation technology, oil atomization ≤ 50um,
multiple opportunities to enhance the gas molecules and water molecules exposed to the
vacuum system and extends the flowing distance in the vacuum system to ensure water
and gas vaporized sufficient time to complete removal of moisture and gas
4.oil level control, pressure control, voltage protection, phase sequence protection etc.
adopts automatic control, the full realization of unmanned control.
5.Heating system adopts low-load design to ensure uniform heating oil, the load is less
than 1.0W/cm2, avoiding cracking and aging of oil.
6.Heating system safety interlock protection control, avoiding heater dry. Adjustable
temperature range of 0-100ºC, the heater control in multiple groups
7.Advanced vacuum defoaming technology to avoid the oil ejecting and gushing during
the process Technical specification| Model | DSF010 | DSF020 | DSF030 | DSF050 | DSF100 | DSF150 | DSF200 | DSF300 |
| Capacity(L/min) | 10 | 20 | 30 | 50 | 100 | 150 | 200 | 300 |
| Working vacuum | -0.06~-0.095 Mpa |
| Working pressure | ≤ 0.4 Mpa |
| Temperature range | 20-80ºC |
| Water content | ≤10 ppm |
| Gas content | ≤ 0.1% |
| Acid Value | ≤0.05 mKOH/g |
| Cleanness | NAS 6 grade |
| Filtering precision | ≤1 micron |
| Continuous work | 100 hr |
| No failure running | ≥5000 hr |
| Power supply | 380V, 50HZ, 3PH ( or Customized ) |
| Working noise | 65 dB |
| Heating power (kw) | 24 | 24 | 30 | 40 | 60 | 90 | 145 | 160 |
| Total power (kw) | 27 | 27 | 33.5 | 44 | 65 | 97 | 157 | 178 |
| Inlet/outlet(mm) | 25 | 25 | 32 | 32 | 48 | 50 | 58 | 65 |
| Weight (kg) | 300 | 350 | 400 | 500 | 800 | 1000 | 1200 | 1350 |
Dimension
(mm) | L | 1100 | 1230 | 1250 | 1500 | 1650 | 1750 | 1900 | 2000 |
| W | 800 | 810 | 850 | 950 | 1000 | 1200 | 1250 | 1350 |
| H | 1250 | 1260 | 1300 | 1400 | 1600 | 1750 | 1950 | 2100 |
Working principleThe oil is sucked into heating system by vacuum and atmosphere pressure difference, after
heating, large mechanical impurities will be removed by coarse filters, then demulsifying
filter separate the mass water from oil and discharge from cooling system. When getting
into big vacuum chamber, the oil become oil mist by sprayer, the moisture dissolved in oil
is evaporated and discharged through vacuum pump. After dehydration, the fine filter will
do precision filtration and 99.5% of particles over 1.0 micron are removed. Then the
cleaned oil is pumped out by oil pump.
