| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Image Sensor: |
CCD |
| Type: |
Digital |
Product Description
Model No.
FV-DM272 SN420
FV-DM272 SP420
Description:
Plastic dome camera for Indoor
Image Sensor
1/4" Sony Super HAD CCD
1/4" SHARP Color CCD
Effective Pixels
PAL: 500(H)x582(V) / NTSC: 510(H)x492(V)
Resolution420 TV Line
TV SystemPAL / NTSC
Lens3.6mm fixed lens
IR LEDN. A
Night VisionN. A
IR LED ControlN. A
Min. Illumination0.5 Lux
IR WaveN. A.
Video OutputBNC / 1.0Vp-p, 75Ω
S/N Ratio>48dB ( AGC on )
Gamma Correction0.45
Electronic ShutterPAL 1/50-1/100, 000Sec, NTSC 1/60-1/100, 000Sec
BLCAuto
AGCAuto
White BalanceAuto
Sync SystemInternal
Operating Temp-10 - 50
Operating Humidity≤ 95 %
Extended Options
1/3" Sony Super HAD CCD, 480TV Line
1/3" SHARP Color CCD, 420TV Line
