CATV Indoor Amplifier 8200
| Price: |
US $ 20-28/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
CATV Indoor Amplifier |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
178(L) X 100 (W) X 55(H) |
| Suitable: |
860MHz CATV Bidirectional Cable Transmission Net |
| Certification: |
RoHS |
| Condition: |
New |
| Function: |
Signal Transmitting Device |
| Type: |
CATV（Cable Television）Equipment |
Product Description
Description
CATV House Amplifier, DT-HA-8200 bidirectional building amplifier, it is suitable to the 860MHz CATV bidirectional Cable transmission network. Forward Path: (Frequency Range: (47)87~862MHz, Rated gain: 30dB, Return Loss: ≥ 14dB), Return Path: (Frequency Range: 5 (30)65MHz, Gain: ≥ 15dB, Return Loss: ≥ 16dB), Power Voltage(50Hz): AC (165~250)V or AC(35~60)V is optional.
Feature
Continuously variable equalizer and attenuator.
Aluminum alloy shell, the overall power consumption is only 8W.
The return path adopts low-noise microwave tube push-pull amplifier circuit.
| Item | Unit | Technical Parameter |
| Forward Path T ransmission |
| Frequency range | MHz | (47)87~862 |
| Rated gain | dB | 30 |
| Min full gain | dB | ≥30 |
| Rated Input Level | dBμV | 72 ±2 |
| Rated Output Level | dBμV | 10 0 |
| Flatness In Band | dB | ± 1 |
| Noise Figure | dB | ≤ 10 |
| Return Loss | dB | ≥ 1 4 |
| C/CTB (84 PAL-D) | dB | ≥58 |
| C/CSO (84PAL-D) | dB | ≥56 |
Signal to Alternative
Noise Ratio | dB | ≤2% |
| Gain Stability | dB | ≤ ± 1.0 |
| Voltage Stroke | KV | 5 |
| AGC Characteristic | dB | ±4 (input) /±0.5 (output) |
| Group Delay | ns | ≤ 10 (112.25 MHz/116.68 MHz) |
| Signal to Hum Ratio | % | < 2 |
| Gain Stability | dB | -1.0 ~ +1.0 |
| Return Path T ransmission |
| Frequency Range | MHz | 5~(30)65 |
| Gain | dB | ≥15 |
| Flatness In Band | dB | ±1 |
| Noise Figure | dB | ≤ 12 |
| Return Loss | dB | ≥ 16 |
| MAX Output Level | dBμV | ≥ 110 |
Carrier to second order
intermodulation ratio | dB | ≥ 52 |
| Carrier to Alternative noise ratio | 2% | <2 |
| Signal to Hum Ratio | % | < 2 |
| General Response |
| Power consumption | VA | 8 |
| Impulse Resisting Voltage | Kv | >5 |
| Power Voltage(50Hz) | V | A:AC (165 ~ 250)V ;B : AC(35 ~ 60)V |
| Dimension | Mm | 178(L) x 100 (W) x55(H) |
