| Prod Model: |
BU-2014 |
| Markets: |
South America,Africa,Eastern Asia |
| Channels: |
4 |
| Frequency Range: |
190-280MHz |
| Type: |
Collar Microphone |
| Battery: |
9V |
| Size Of Receiver: |
480*180*44mm |
| Signal Transmission: |
Wireless |
| Application: |
Meeting |
Product Description
1. Four channels. Each channel has a fixed frequency.
2. Oscillation: Quartz crystal
3. Carrier frequency range is VHF 190MHz-280MHz. Frequency displayed on the screen will be 700MHz-900MHz.
4.16 fixed frequency can be used at the same time. That means 4 receivers and 16 transmitters can be used at the same meeting.
5. LCD screens on the receiver will display working channel, working frequency and signal level. Each screen will display informations of 2 channels.
6. On the back panel of the receiver, there are 2 pull rod antenna for signal receiving.
7. There are 2 blanced output and 1 unblanced output on the back-panel, suitable for linking up with other audio equipments.
8. Microphone power consumption is 60mA. With two 1.5V battery power supply, it can work constantly for 8 hours.
9. Working distance: Open environment: 50-70 meter. Complicated environment: 30-50meter.
10. It's suitable for various kinds of conference and performance occasion.
Patameter:
Channel number: 4
Oscillation Mode: Quartz crystal
Modulation Mode: FM
Carrier Frequency Range: UHF 700~900MHz
Frequency Stability: +0.001%
Max. Deviation Range: +50kHz
S/N Ratio: > 105dB
T. H. D: < 0.5%@1kHz
Sensitivity: 1.2/UV@S/N=12dB
Power Supply: DC 12~17V
Audio Output: Independent: 0-400mV
Mixed: 0-300mV
