4 Channel 3G Mobile DVR Car DVR System for Bus Truck, Support 1tb HDD and 128GB SD Card to Storage

Name: 4 Channel 3G Mobile DVR Car DVR System for Bus Truck, Support 1tb HDD and 128GB SD Card to Storage
Brand: ec-portal.com
SKU: 758109985
Availability: InStock
Rating: 4.6 (99 reviews)

Price:	US $ 99-299/Piece
Trade Terms:	FOB,FCA,EXW
Min Order:	2/Piece
Pay Type:	T/T,Western Union

Send Inquiry

Showroom Product Company Profile

Prod Model:	VC-MDRH8000 CAR DVR
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Voltage:	8-36V Wide Range Voltage Input
Shockproof:	Super Double Universal Shockproof System
G-Sensor:	Built in G-Sensor Module
Wireless:	Support GPS, 3G, WiFi for Optional
Storagy:	Support SD Card and Hard Disk Storage
Alarm:	Multiple Sensor Alarm and Alarm Linkage
PTZ:	Support Local and Remote PTZ Control
Video:	4 Chnnals Video Input, 1 Channal Video Output
Audio:	2 Channal Audio Input, 1 Channal Audio Output
Application:	Commercial DVR
Operating System:	Linux
Compressed Format:	H.264
Video Compression:	H.264
Audio Input/Output:	4 Channel
Video Input/Output:	4 Channel
Remote Control:	With Remote Control
Type:	Car DVR for Mobile Security
Interface Type:	Airplug

Product Description

H. 264 3G GPS WIFI Gsensor Vehicle Mobile Security DVR with HDD and SD Card Storage

Model: VC-MDRH8000 VC-MDRS8000

Description:
VC-MDRH8000 / VC-MDRS8000 is a high level hard disk / SD card mobile digital video recorder specially designed for vehicle surveillance purpose. It adopts high speed processor and embedded operating system, integrates latest H. 264 AV codec standard, high capacity hard disk storage, mature shock absorption technology, network streaming media, AV noise reduction, wide range voltage design and patent power-off protection technology, support WIFI, 3G, GPS for optional, brief outward, easy installing, system is safe and reliable.

Functional Feature:

8-36V wide range voltage input, with overvoltage protection function.
Super double universal shockproof system
Built in G-sensor module
Support GPS, 3G, WIFI for optional
Support SD card and hard disk storage
Support advertising screen docking, support mobile surveillance(for optional), support communication with peripheral equipment
Patent UPS power-off protection technology
Support trajectory playback
GPS over speed alarm, acceleration alarm, motion detection alarm
Support alarm trigger capture
Phone dialing function, IP call function, disk preheating (for optional)
Mobile monitoring center platform management software (for optional)
Data redundant storage technology
Support local and remote PTZ control
Startup recording by default, support auto timed, alarm & manual recording
Support to connect speed sensor input, speed audio video synchronous recoding.
Multiple sensor alarm and alarm linkage
Support to record multiple status, such as open the door, brake, turn, whistle.
External dimension: 142(W) x62(H) x123(D) mm 142(W) x36(H) x123(D) mm

Item		Description
Operation system		Linux
GUI		Setup system parameters with remote controller
Security management		Support user password, supervisor password management; support encryption transmission
Video	Video input/output	4-channel video input, 1-channel video output; 1.0Vp-p, 75Ω
	Dual stream	Support
	OSD	Time & date, vehicle ID, GPS etc
	Compression	H.264. Hisilicon high performance processor is applied.
	Preview function	Single channel, 4-picture splicing preview, support event triggered full screen and splicing switching display function
	Video frame rate	PAL: 100 frame/sec, up to 25 frame/sec for single channel NTSC: 120 frame/sec, up to 30 frame/sec for single channel
	Video resolution	CIF, HD1, D1,4D1 adaptive
	Video quality	Level 1 to 4 video quality adaptive, level 1 best, level 4 lowest
	Video Bit Rate	CIF: 256Kbps ~ 1.5 Mbps, 8 levels of bit rate optional HD1: 600Kbps ~ 2 Mbps, 8 levels of bit rate optional D1: 800Kbps ~ 3Mbps, 8 levels of bit rate optional 4D1: 800Kbps ~ 4Mbps, 8 levels of bit rate optional
Audio	Audio input/output	1-channel input; 1-channel output
Audio	Compression	G.726
Recording	Storage media	H8000 support Hard Disk+SD card, S8000 support only SD card
	File format/system	ASF/ FAT32
	Recording mode	Startup recording by default, support auto,timed, alarm & manual recording
	Recording search	Search recording video files by time, type, storage device, etc.
	Recording playback	Support local playback, support up to 4-channel synchronous playback, and analyze the vehicle message in the file at the same time
	Recording playback	Support fast forward, fast backward, play, pause controls, support 2, 4, 8, 16 times speed fast forward or fast backward, support the control of playback by time
Alarm	Alarm input	5-channel I/O alarm input
	Alarm recording	Pre-recording function, 15 seconds pre-recording of alarm, recording time after alarm can be adjusted in between 30 sec ~ 30 min
	Alarm output	2-channel alarm output
	Storage space	Support the setting of remain storage space alarm function
	Functional alarm	Overspeed alarm, gsensor alarm, voltage alarm,snapshot alarm, motion detection alarm
Communication interface		RS232, RJ45 10M/100M self-adaption Ethernet interface
Wireless transmission (optional)		Built-in 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA system optional; Compatible with GPRS, EDGE; Built-in Wi-Fi module for optional;
GPS (optional)		Support external GPS module
Data remote transmission		Support 3G/Wi-Fi transmission, Wi-Fi priority transmission strategy, remote download;
PTZ control		Support PTZ control function by local remote controller or client software;
Parameter configuration		Support parameter configuration
G-sensor		Built-in
System upgrade		Support hard disk and SD card / Remote upgrade
Power supply & consumption	Power supply management	ACC startup/shutdown; Hard disk lock startup/shutdown; Delay shutdown; Timing startup/shutdown
	Input voltage	DC:+8V ~ +36V
	Output voltage	+12V@4*0.5A;[email protected]
	Power-off protection	Patent UPS power-off protection technology for optional, ensure the integrality of recording data when accidental power failure occurs
	Power consumption	Less than 10W in normal working state; less than 0.5W in standby mode
Working environment	Temperature	Normal: 0 ~ +60 degree Hard disk pre-heating: -25 ~ +60 degree
Working environment	Humidity	10% to 95%
Dimension		H8000:142(W) x62(H) x123(D) mm, S8000:142(W) x36(H) x123(D) mm
Weight		H8000:net weight:1000g , S8000:net weight:550g
