| Prod Model: |
WVT-TP4-4.5A0 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Transparency: |
≥ 80% |
| Product Status: |
Stock |
| Working Voltage: |
5.0V |
| Certificate: |
CE, RoHS |
| Price: |
Best Price |
| Operate System: |
Windows 2000-XP/98/CE |
| Warranty: |
1 Year |
| Life Time: |
Over 1 Million Touches |
| Product Name: |
Resistive Touch Screen |
| Storage Temperature: |
-40°c to 90°c |
| Certification: |
RoHS |
| Video Output: |
Resistive Touch Screen |
| Audio Output: |
Resistive Touch Screen |
| Voltage: |
5V |
| Placement: |
on The DVD |
Product Description
4.5'' touch screen car DVD player
1. 4 Wire resistive touch screen.
2. 1.0mm pitch.
3. OEM for customer.
4. Offer 1year warranty
Feature:
Panel size: 1.0'' to 22"
Power: USB
Response time: 10ms
Life span: > 1, 000, 000 touches
Linearity: ≤ 1.5%
Transmittance: ≥ 82%
Resistance: 200 ~ 950 0Hms
Surface durability: ≥ 3H
Operating temperature: -10° C - 60° C
Works With The Operating Systems:
Windows 2000-XP
Windows 98
Windows CE
Linux
DOS
Ideal for use as POS (point of sale) or for giving directions or instructions touch screens are an eye-catching and technologically advanced way to communicate in pretty much any business:
Advantage:
--Low cost solution, Low power consumption
--To be activated with any device
--Finger, gloved hand and stylus activation
--High accuracy and sensitivity
--High durability and reliability
--Contaminant proof and liquid resistance.
Application
--Light industrial
--Home appliances
--Portable sport devices
--Access control terminals
--Portable medical devices
--Personal computer and office.
Package included:
Controller board
Connecting cable
Software
USB cable
|
Size |
1.8" - 23" |
|
Constrcution |
Glass, uniform resistive coating, polyester coversheet, transparent insulating dots, conductive coating |
|
Operating Force |
10g~100g |
|
Chattering |
≤12ms |
|
Surface Hardness |
Moths 3 |
|
Life Time |
More than 1 million touches in one location without failure |
|
Transparency |
≥80% |
|
Working Voltage |
5.0V |
|
Circuit grade |
DC5V 1mA |
|
Insulation impedance |
≥20MΩ(25V DC) |
|
Linearity |
≤1.5% |
|
Operating Temperature |
-30°C to 80°C |
|
Storage Temperature |
-40°C to 90°C |
|
Operating Humidity |
20%RH ~ 90%RH |
|
Storage Humidity |
10%RH ~ 90%RH |
|
Warranty |
1year |
|
No noted size common difference |
±0.20
|
