Product Description
This is 100% compatible with MSR206 the very durable Black Manual Swipe Magnetic Card Reader Writer, Series is designed to offer a card reading/writing solution for ISO 7811-6 and many other international standard formats. The M80 reads and writes up to 3 tracks of data, e. G. Decoding/encoding and verifying up to 3 tracks of data. This machine comes with USB standard connection to the host computer. The M80 is manufactured at our ISO 9001 certified factory and comes with a 1-year warranty.
Feature
Reading/Writing magnetic stripe card complied with ISO formats
Read/Write High & Low Coercive (300~4000Oe) really 4000OE
High/Low Coercivity encoding circuitry selectable on screen
Program software for Windows 98/Me/XP
Sequential write function, up to 12 digits (1 up)
Manual Swipe to read and/or write card with USB output
+24VDC, 2.5A Max external power adapter attached
Dimensions of 210(L) x 60(W) x 62(H) mm
Specification
Electrical
Power requirements: +24VDC +/- 5%
Consumption: Typical 350mA Max. 600mA plus for each writing track
Power supply: External switching power 24V/2.5A
Communication: Standard USB cable
Ripple: 50MVP-p or less
Dielectric strength: 500 VDC for 1 minute
Performance: Read card Track1 Track2 Track3
Bit per density: 210 bpi 75/210bpi 210 bpi
Coercive force: Read/write 300-4000 oe Mag. Card
Card thickness: 0.76-1.2mm
Read speed: STD card Jitter +/-15% Amp. 60% 5-55IPS
Write speed: 5-30IPS
Write jitter: Interval < +/- 10%, Sub-interval < +/- 12%
Error rate: Read < 0.5% Write < 0.8%
Head life: Min. 1000K swipes for both read/write head
Mechanical: Body material: ABS 94V-0
Weight: Approx. 1.5kg
Dimension: 210.1L x 60W x 62H mm
Swipe: Manual, single direction
Environments
Operation
-10 to 55oC, 10 to 85% humidity
Storage
-30 to 70oC, 10 to 90% humidity
Safety Approval
Rating
FCC Class B, CE ClassB, UL, cUL, ROSE
Box Contents:
1 M80 USB
1 Power Cord with Adapter
1 Clean card
10+10 Blank Magnetic Stripe Card(4000 OE)
1 Software CD
