| Prod Model: |
camera wireless XY-1281WT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Resolution(TV Line): |
420 |
| Effective Pixels: |
580*492 |
| IP Rating: |
IP68 |
| Qty: |
50PCS |
| Interface: |
RCA |
| Definition: |
420TVL |
| Chip: |
CCD |
| Waterproof Grade: |
IP67 |
| Probe Number: |
No |
| Alarming Distance: |
No |
| Probe Diameter: |
No |
Product Description
2.4G Wireless system for 24V bus
Car camera with reverse guide line (with high resolution low lux sensor, wide view lense)
CCD Car back up rear view camera with reverse parking line
(with high resolution low lux sensor, 170 degree)
With IP67 high level waterproof, durable for vibration, high/low temp, long time working conditions
Small Size Camera Good For In-built Fixing
High Dynamic Range Sensor
Waterproof Car Camera Module
Superior low light performance
Super Wide View Angle
Transfer Frequency: 2370MHZ
Wireless Power Consumption: 100mW
TV system: PAL/NTSC
No Obstructed Transfer Distance: 100M
Receiver Sensitivity: -85Dbm
Working current: 200mA
Working Voltage: 12V DC
Output Voltage: 12V DC
Working Temperature: -20° C+80° C
Images sensors
| Best Quality
| Normal Quality
|
Resolution(TV Line)
| 480
| 420
|
Effective pixels
| 668*580/668*512
| 580*540/580*492
|
Minimum illumination
| 0.5 lux
| 1 lux
|
IP rating
| Ip68
|
lens Angle(Deg.)
| 170°
|
TV System
| PAL/NTSC
|
Power Supply(DCV)
| DC24V±1V
|
Power
| <1W
|
Electronic shutter
| 1/60(NTSC)1/50(PAL)1/10,000second
|
S/N Ratio
| ≥48dB
|
Video output
| 1.0vp-p.75ohm
|
White Balance
| Auto
|
AGC
| Auto
|
Operating Temperature(Deg. C):
| -20~+75(RH95% Max.)
|
Storage Temperature(Deg. C):
| -30~+85(RH95% Max.)
|
---------------------------------------------------------------------------------------------------------
Welcomes All Customers Vistor Our Factory and Happy to do Business with all overseas
Note: We have strict producing process, aging test and QC to make sure high quality production.
We have established systematic production standard in waterproof, shockproof, temperature resistance,
Humidity resistance, high definition.
Competitive advantage
1. Stable quality (CE FCC ROHS)
2. Most competitive price
3. On time delivery
4. Good aftersales service
5. All products must test one by one wartproof resistance and high/low temperature resistance
6. Warranty: 16months
7. OEM, ODM welcome
Guangzhou X&Y Electronics Co., Ltd. Was established in Guangzhou in 2005. We are a hi-tech enterprise engaged in the R&D, production, and sale of car camera system, car DVR camera. We guarantee punctual delivery, competitive price and prompt response. We welcome your inquiries and look forward to establishing long-term business relationships with you in the near future.
------------------------------------------------------------------------------------------------------------------------------
| Company Phone: +86-20-29036269 +86-20-29011872 |
| Company Name: Guangzhou X&Y Electronic Co., Ltd. |
| Website: http://www.xyglobal.cn |
XY Car Electronic Limited is the professional company in car visible parking and driving security system areas, since 2005.
We are the professional car driving safety electronic production system supplier with 9 years produce and export experience, and offered excellent OEM ODM service to world wide well know famous brands.
Main production is Car Camera, Car TPMS, Car DVR Driving Recorder, Parking Sensor, Car Monitor, Car Alarm, Car GPS Tracker.
After years of developing, we have formed strong ability in new production development, and strict quality control system to ensure excellent quality and service.
With strict material and producing quality control, we offer 1 year warranty
And less than 0.3% faulty rate production to our customers.
With the support of many long term strategy cooperate customers, our prodctions are welcomed all over the world.
Our Product Concept: Help Mastering Your Car!
We offer OEM/ODM service to oversea customers.
Welcome to cooperate with X&Y to get win&win success.
