Water Cooled Packaged Central Commercial Air Conditioner in China
| Price: |
US $ 900-10000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
ESSW05SC-ESSW52.5FC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Compressor Brand: |
Danfoss/Copeland |
| Safety Protection: |
Multi Protections |
| Type: |
Cabinet Air Conditioner |
| Mounting: |
Floor Standing |
| Condition: |
New |
| Operating Voltage: |
380~440V-3pH-50Hz/60Hz |
| Application Fields: |
Villa/School/Hotel/Factory |
Product Description
Water Cooled Packaged Central Commercial Air Conditioner in China
1. Packaged air conditioner main features:
(1) Advanced high efficiency flexible scroll compressor; (2)Micro-computer intelligent controller; (3) Multiple safety protections; (4) Superior quality or capillary tube.
2. Nomenclature-Water cooled central packaged air conditioner
ES S W 26.5 PT T C E
1 2 3 4 5 6 7 8
1: ES Eurostars
2 :S Compressor type: S-Scroll G-Screw P-Hermetic piston B-Semi-hermetic piston R-Rotary
3 :W Product series No.: W-Water cooled commercial series
4 :26.5 Cooling capacity:USRT
5 :PT Product type: PT:Purified thermostatic and humidistat PU: Purified
HT: Thermostatic and humidistat
6 :T Compressor quantity: S-Single D-Double T-Triple Q-Quadruple F-Fivefold
7: C Frame type: C-Cabinet type O-Open type
8 :E Function: H-Heat pump E-Electrical heating
Cooling or Heating only- when not to mention any letter
3. Water cooled packaged air conditioner installation illustration:
4.Water cooled Packaged air conditioner techinal specification
Please ask salesman for detailed complete data or visit our website:
www.eurostarschina.com | Water Cooled (Electrical Heating)Packaged Air Conditioner |
| Model ESSW | 05SC | 7.5DC | 9.5DC | 14.5TC | 19DC | 21.5DC | 26TC | 35.5QC | 43QC | 52.5FC |
| 05SCE | 7.5DCE | 9.5DCE | 14.5TCE | 19DCE | 21.5DCE | 26TCE | 35.5QCE | 43QCE | 52.5FCE |
Technical
Parameters | Cooling Capacity | HP | 5 | 8 | 10 | 15 | 20.0 | 25.0 | 30 | 40 | 50.0 | 60.0 |
| USRT | 4.78 | 7.54 | 9.53 | 14.36 | 18.77 | 21.62 | 26.17 | 35.55 | 43.23 | 52.62 |
| KW | 16.8 | 26.5 | 33.5 | 50.5 | 66.0 | 76.0 | 92 | 125 | 152.0 | 185.0 |
| Electrical Heating capacity | KW | 6 | 9 | 12 | 18 | 22.5 | 27 | 36 | 48.6 | 64.8 | 72 |
| Rated Air Flow | m3/h | 2500 | 4000 | 5100 | 7800 | 10200 | 12600 | 15300 | 20400 | 25500 | 30000 |
| External Static Pressure | Pa | 100 | 150 | 150 | 150 | 200 | 250 | 300 | 350 | 400 | 400 |
| Power Supply | | 380V-3Ph-50Hz |
| Running Power | KW | 4.0 | 6.5 | 8.2 | 12.1 | 15.3 | 17.8 | 22.3 | 30.3 | 37.1 | 47.2 |
| Running current | A | 8.5 | 13.5 | 16.6 | 24.6 | 30.4 | 34.2 | 44.5 | 60.0 | 70.2 | 90.1 |
| Cooling Input power | KW | 5.8 | 9.3 | 11.7 | 17.4 | 21.9 | 25.2 | 31.4 | 42.7 | 51.9 | 65.2 |
| Cooling Current | A | 12.0 | 19.2 | 23.6 | 35.0 | 43.1 | 47.9 | 62.4 | 84.2 | 97.6 | 123.9 |
| Heating Input Power | KW | 6.5 | 9.8 | 13.1 | 19.5 | 24.7 | 30.0 | 40.0 | 54.1 | 72.3 | 83.0 |
| Heating Current | A | 11.2 | 16.4 | 21.9 | 32.5 | 41.0 | 50.0 | 66.4 | 89.3 | 119.0 | 137.8 |
| Noise | dB(A) | ≤60 | ≤62 | ≤64 | ≤68 | ≤70 | ≤72 | ≤73 | ≤73 | ≤76 | ≤78 |
| Compressor | Type | | Hermetic Scroll Type |
| Qty | | 1 | 2 | 2 | 3 | 2 | 2 | 3 | 4 | 4 | 5 |
| Power | KW | 3.5 | 5.7 | 7.1 | 10.6 | 13.1 | 14.8 | 18.3 | 24.8 | 29.6 | 36.2 |
| Fan | Type | | Outer Rotor | Belt Transmission Centrifugal Type |
| Qty | | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Power | KW | 0.45 | 0.75 | 1.1 | 1.5 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 |
| Air Filter | Nylon Netting |
| Evaporator | High Efficiency Ripple Aluminum Fins Around Copper Pipe |
| Refrigerant | R22/R407C |
| Condenser | Type | Shell and Tube Type |
| Cooling Water Flow | m3/h | 3.5 | 5.5 | 7.0 | 10.5 | 13.6 | 15.6 | 19.0 | 25.8 | 31.2 | 38.0 |
| Water Pipe Diameter | in. | 1-1/4 | 1-1/2 | 1-1/2 | 2 | 2 | 2 | 2-1/2 | 3 | 3 | 3 |
| Condensate Water Drainage Pipe Diameter | in. | 1 | 1 | 1 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 | 1-1/4 |
| Water Drain Pipe Diameter | in. | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 |
| Safety Protection Device | High/low pressure switch protection, Compressor overload Protection over current protection,
Phase sequence protection, Start delay protection, Oil heater, Cooling water flow too little
protection, Electric wire overheating protection,The fusible plugs, Fuse, etc. |
| Dimension | Width | mm | 800 | 960 | 1200 | 1700 | 1700 | 1700 | 1880 | 2050 | 2450 | 2450 |
| Depth | mm | 550 | 520 | 600 | 600 | 750 | 750 | 1090 | 1150 | 1300 | 1300 |
| Height | mm | 1770 | 1730 | 1730 | 1780 | 1830 | 1830 | 1930 | 1930 | 1990 | 1990 |
| Net Weight | kg | 225 | 300 | 360 | 480 | 660 | 700 | 890 | 1100 | 1560 | 1800 |
Note:
(1). Rated Cooling Capacity based on:Entering Air Temperature 27ºC/19.5ºC,Inlet/Outlet Cooling Water Temperature 30ºC/35ºC;
(2). Entering Air Temperature:18ºC-30ºC,Control Accuracy ±2ºC;
(3). Cooling Water Inlet Temperature:21-34ºC;
5.Eurostars water cooled packaged air conditioner Quotation Remarks
(1).Packing: Standard export package
(2).Delivery Day: 25 days after deposit is confirmed
(3).Delivery term: CIF,FOB or CNF EX-Work are welcomed
(4).Payment term: 30% deposit by TT, the balance will be paid by TT before delivery;
or 100% Irrevocable non-transferred LC at sight
(5).Warranty: 12~18 months after Bill of Lading date. Any unartificial failure occurred within the
period, we'll supply you the spare parts for free, and permanent technical support & consultation all
life long for the machines.
(6).Validity: 20 days
(7).Payment currency: USD
