Connector Code |
Connector Figure |
|
Radio Models |
K |
|
|
KENWOOD:TK-272G/372G,TK3130 ProTalk XLS, TK-3131 Free Talk XLS, TK-220/320,240/340, 240D/340D,TK208/308,430/431,250/350/353, TK260/270,260G/360G,360/370,270G/370G, 248/348, 2100/3100, 2160/3160 ProTalk, 3101
FreeTalk XL 2102/3102 ProTalk... etc. Radio |
K1 |
|
|
KENWOOD: TK480/481, 290/390/280/380,
TK-2140/3140...etc. Radio |
M |
|
|
MOTOROLA: GP300, SP50, P110, P-1225/P1225LS, LTS2000, CP88,
CP150, CP200, CT150, CT250, CT450, CT450LS, GP308, P080,
P2000, PRO2150, PRO3150, P040, P080, GP68, GP88, PR400,SP10,
Sp21, XTN500, XTN600, PRO1150, CP100, PMR446, XTN446,
XU1100, CLS1110, CLS1410, XU2600 ... etc. radio,HLN9716,
HLN9482A... etc. Adaptor |
M1 |
|
|
MOTOROLA: VISAR radio, BDN6676, HLN9717, PMLN4455 adaptor
Plug type: Ø 3.5mm S/P thread |
M2 |
|
|
MOTOROLA: Spirit GT/ Spirit GT+/ Talkabout 270, 280/T289,
T5100, T5200, T5600, T5620, T5700, T5720, T5800, T5820,
T7200, fr50/f60... etc. FRS radio |
M3 |
|
|
MOTOROLA: XTS3000/Astro, XTS3500, XTS2500/XTS5000
and HT-1000 Series (HT-1000, MT2000, MTS3000, MTX8000,
MTX838, MTX9000, MTX-LS, JT1000), Gp900... etc. Radio |
M4 |
|
|
MOTOROLA: HT750, HT1250, HT1250LS, HT1550/HT1550XLS,
MTX850/MTX850LS, MTX8250/MTX8250SL, MTX950/MTX9250,
GP140, GP320, GP328, GP338, Gp340,GP360, GP380, GP640,
GP1280, PRO5150, PRO9150... etc. Radio |
M5 |
|
|
MOTOROLA: GP-344/388, GP-328+/338+, EX-500/600, GL-2000... etc. Radio |
M6 |
|
|
MOTOROLA: MTH500, MTH650, MTH800, MTP850... ect. radio.
Plug type: Ø 2.5mm S/P with copper ring |
|
|
MOTOROLA: MTH500, MTH650, MTH800... Etc. radio.
Plug type: Ø 2.5mm S/P with copper ring |
M7 |
|
|
Motorola Multiple-Pin
Motorola Mototrbo DGP4150/4150+/6150/6150+
Motorola Mototrbo DP3400/3401/3600/3601
Motorola Mototrbo XiR P8200/8208/8260/8268
Motorola Mototrbo XPR6300/6500/6550 |
M8 |
|
|
|
Y |
|
|
VERTEX/YAESU: VX-400, VX-410, VX-420... etc. radio
Plug type: Ø 3.5mm S/P 4C |
Y1 |
|
|
VERTEX/YAESU: VX-400, VX-410, VX-420... etc. radio
Plug type: Ø 3.5mm S/P 4C |
Y2 |
|
|
VERTEX/YAESU: VX-210 , VX-210A, VX-150, VX-160, VX-180,
VX-246... etc. radio
Plug type: Ø 3.5mm S/P 4C |
Y3 |
|
|
VERTEX/YAESU: VX-600, VX-800, VX-900... etc. Radio |
Y4 |
|
|
VERTEX/YAESU: VX-7R... etc. radio
Plug type: Ø 3.5mm S/P 4C thread |
