Switch Amplifier (FP10000Q) , Power Amplifier, 4 Channel Amplifier, 1300W X 4
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Money Gram |
| Prod Model: |
FP10000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Type: |
Professional Amplifier |
| Used For: |
Professional |
| Tube Type: |
Tube Amplifier |
| Function: |
Post Amplifier |
| Sound Channel: |
4.1 |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
Product Description
Model FP10000Q
8ohm Stereo Power(RMS): 1300WX4
4ohm Stereo Power(RMS): 2100WX4
2ohm Stereo Power(RMS): 2500WX4Features:
1: FP series is uses new FM-wide regulator would be get more power technology. It is a small size ,low weight and high efficiency ,high power and high reliability. Both mobile and fixed installation performance are the best choice for you .2: Fidelity output:High-efficiency amplifier output circuit , small size ,high power density,Hifi-lever tone .3: Perfect protection system:It has full function protection, it includes power soft start,overload and short circuit,DC, overheating ,UHF, clipping limiter function,especially without output relay protection, it has reflected the rapid,accurate, is the relay cant not be compared. | Model | FP10000Q |
| Output Power | 20-20kHz, 1W with 1 khz |
| 8Ω Stereo Power(RMS) | 1350WX4 |
| 4Ω Stereo Power(RMS) | 2100WX4 |
| 2Ω Stereo Power(RMS) | 2500WX4 |
| 8Ω Bridged Power(RMS) | 4200WX2 |
| 4Ω Bridged Power(RMS) | 5000WX2 |
| Frequency Response(+o/-0.3dB, 1W/8Ω ) | 20 Hz - 34 kHz |
| THD 20 Hz - 20 kHz for 1 W | < 0.1% |
| Signal-to-Noise Ratio | > 112 dBA |
| Channel separation (Crosstalk) at 1 kHz | > 70 dB |
| Input Connectors (per channel) | 3-pin XLR, electronically balanced |
| Output Connectors (per channel) | Binding Posts 2-pole |
| Class | TD |
| TourClass Protection | ACL, IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input |
| Operating voltage, 230 V / 115 V nominal | 130-265 V / 65-135 V selectable |
| Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
| Input impedance | 20 kOhm |
| Level adjustment (per ch. ) | Front-panel potentiometer, 31 position detented from -inf to 0 dB |
| Dimensions (W× H× D) | 483× 88× 396mm |
| Packing dimension | 560× 180× 500mm |
| Net weight(kg) | 15 |
| Gross weight(kg) | 18 |
Guangzhou Hao Yang PRO Audio Manufactory was founded in 1998, a number of its brands; Agent and a number of famous foreign brands, such as: The United States, Factory is a specialized professional stage doing fine speaker, professional audio equipment and digital audio system for R & D and production, sales in one of the producers; Warm service units in order to survive, quality assurance, stability, technological innovation and development, domestic and foreign customers for the cost-effective professional audio equipment.
Professional audio equipment factory targeted for its strong and took advantage of a variety of applications, According to the designers of the product adaptation to different characteristics of the product structure and configuration of the different functions of the formation of a series of widely used in high-end KTV, theaters, sports venues, outdoor performances, nightclubs, indoor SHOW it, the stage bars, Multi-function hall and many other places use the product line. Our products may not be the best, but our product is the most applicable, the most reliable, most cost-effective!
At the same time, in the bigger, stronger, do a good job in their own brand names outside the factory for domestic and foreign customers with OEM, ODM services for customers with special needs box processing services.
