New Fp20000q Amplifier with 4 Channel 4000W. Audio Equipment, Subwoofer Amplifier
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
FP20000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Rated: |
2200W X 4 @ 8 Ohms |
| Color: |
Black |
| Damping Factor: |
1300 |
| Use: |
Events |
| Type: |
Professional Amplifier |
| Usage: |
Outdoor |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Function: |
Pre-amplifier |
| Sound Channel: |
4.1 |
| Output Number: |
8 |
| Element Number: |
Monoamplifier |
| Conductive Mode: |
D |
| Voltage: |
110V and 220V |
Product Description
FP20000Q Power Amplifier:
Excellent heat dissipation system: High efficiency double short duct fins copper strip, maintaining the output transistor in the same temperature, the cooling performance is several times than the aluminum radiator.Dual transformer engine:Dual toroidal transformer power supply with high efficiency , maximum power in 2U space, rich low frequency, , it isone of the best fixed installation. | Model | FP20000Q
|
| Output Power | 20-20kHz, 1W with 1 khz |
| 8ΩStereo Power(RMS) | 2200WX4 |
| 4ΩStereo Power(RMS) | 4000WX4 |
| 2ΩStereo Power(RMS) | 5000WX4 |
| 8ΩBridged Power(RMS) | 8000WX2 |
| 4ΩBridged Monon Power | 10000WX2 |
| FREQUENTY RESPONSE | 20Hz-25kHz +-0.5dB |
| THD+N(Rated power | 4Ω/KHz)%:<0.1%
|
| Signal Noise Ration(dB) | 110dB |
| Damping coefficient | 1000 |
| Input gain | 23,26,29,32,35,38,41,44dB |
| Input connectors | Combo XLR type,3pin(NEUTRIK)
|
| Link Connectors | XLR type,3pin male(NEUTRIK) |
| Input Impedance | 20kΩBalanced /10kΩUnbalanced/10kΩUnbalanced
|
| Output Connectors | Speakon Connectors(NEUTRIK)
(NEUTRIK) |
| Protection | Short circuit, open circuit, thermal, overload
DC, super audio and other protective devices |
| Power Requirement | 200-240V~50-60Hz
|
| Minimun power-up voltage | 180-260V~50-60Hz |
| Dimension | 483x377x88mm |
| Packing Dimension | 575x555x140mm |
| Weight(net) | 18Kg |
| Gross weight | 21.5kg |
Guangzhou Hao Yang PRO Audio Manufactory was founded in 1998, a number of its brands; Agent and a number of famous foreign brands, such as: The United States, Factory is a specialized professional stage doing fine speaker, professional audio equipment and digital audio system for R & D and production, sales in one of the producers; Warm service units in order to survive, quality assurance, stability, technological innovation and development, domestic and foreign customers for the cost-effective professional audio equipment.
Professional audio equipment factory targeted for its strong and took advantage of a variety of applications, According to the designers of the product adaptation to different characteristics of the product structure and configuration of the different functions of the formation of a series of widely used in high-end KTV, theaters, sports venues, outdoor performances, nightclubs, indoor SHOW it, the stage bars, Multi-function hall and many other places use the product line. Our products may not be the best, but our product is the most applicable, the most reliable, most cost-effective!
At the same time, in the bigger, stronger, do a good job in their own brand names outside the factory for domestic and foreign customers with OEM, ODM services for customers with special needs box processing services.
