| Prod Model: |
Sanway SP480 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
4 in & 8 Output Processor |
| Power: |
25 Watts |
| Power Supply: |
AC 110V/220V 50Hz/60Hz |
| Noise: |
<95dB |
| Application: |
Commercial |
| Certification: |
RoHS |
| THD: |
0.005%-0.01% |
Product Description
4 In Audio Processor, SP480 Digital Speaker Management Processor
1) 96k Hz sampling frequency, 24-bit A/D and D/A converter, 32-bit DSP processor
2) Input channel With 6-band parameter EQ, Delay, polarity
3) Output channel With 6-band parameter EQ, Gain, Delay, Polarity, Crossover,
Limiter/Compressor, Signal select.
4) Build in USB & RS 485 COM
5) Program Function; Recall Function; Copy Function; Save Function; Password Function.
6) 6-band EQ: Frequency, gain & Q fact are adjustable;
Gain can be adjusted from -20 dB to +20 dB.
| Model | SP480 4input&8output Digital Speaker Management |
| Input Impedance | Balance: 20KΩ |
| Output Impedance | Balance: 100Ω |
| PC Com Port | One USB Com Port on front panel, 2 Rs485 Com Port on back panel(RJ-45) |
| CMRR | >70dB@1KHz |
| Input Level | ≤+25dBu |
| Frequency Response | 20Hz~20KHz ±0.5dB |
| S/N R | >110dB |
| THD | <0.01% @OUTPUT=0dBu/1KHz |
| Crosstalk of Channels | >80dB@1KHz |
| Delay Time Step | Each input channel has independent delay control, Range:0~1000mS; 21μS step@0~10mS; 84 μS step@ 10mS~20ms; 0.5mS step@ 20mS~1000mS |
| Input/Output Polarity | In-phase(+) or reversed phase(-) |
| Input EQ | 6-band parameter EQ; Frequency: 20Hz~20KHz; Gain:-20 dB~+20 dB; Bandwidth: 0.05oct~3oct |
| Mute | Mute with each Input& Output channel |
| Input Selection | Each input channel can be selected to each output channel |
| Output Gain | Range:-12dB~+12dB, step: 0.1dB |
| Crossover | Each output channel can be independently set as LPF and HPF. The parameters can be adjusted. Filter type :Linkwitz-Riley; Bessel; Butterworth. The Crossover Frequency: 20Hz~20KHz, Slope: 12dB/oct; 18dB/oct; 24dB/oct;48dB/oct. |
| Limiter | Limiter with each output channel. The parameters are adjustable: Threshold value: -20dBu~+20dBu; step:0.5dBu. Attack time: 0.3mS~100mS. 0.1mS step at 0.3~1mS; 1mS step at1mS~100mS. Release Time: Release Timecan be set as twice, 4times, 6times, 8times, 16times, 32times. |
| Output EQ | Each output channel has 6-band EQ: 3 modes: Lo-Shelf/Hi-Shelf/Parameter. A: Lo-Shelf: Slop: 6dB/12dB; Frequency:20Hz~20kHz; Gain: -20dB~20dB; B: Hi-Shelf: Slop: 6dB/12dB; Frequency: 20Hz~20kHz; Gain:-20dB~20dB; C: Parameters:frequency: 20Hz~20KHz, bandwidth: 0.05oct~3oct; Step: 0.05oct; Gain: -20dB~+20dB, Step 0.1dB |
| Processor | 96KHz Sampling frequency, 32-bit Floating-Point DSP |
| Display | With 2*24 LCD, 8-LED input/output level. Mute and Editing mode can be displayed. |
| Power | ≤25W |
| Power Supply | AC 110V/220V 50Hz/60Hz |
| Dimension(L×W×H) | 482×232×44mm |
| Gross Weight | 5.0kg |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
