| Prod Model: |
Shouting-NP02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inner Tank: |
Stainless Steel |
| Outer Tank: |
Galvanized Steel |
| Insulation: |
High Density Polyurethane Foam 50mm |
| Bracket: |
Galvanized Steel |
| Collector Components: |
Glass Vacuum Tube |
| Pressure: |
Unpressurized |
| Structure: |
Compact Type |
| Interior Material: |
Stainless Steel |
| Certification: |
CE,Keymark,Sabs |
Product Description
Charateristics
This type uses all-glasses evacuated tubes as the solar collector for absorbing and transferring the sun energy into heat energy. The high absorption and low emittance rate of vacuum tube layer coating is unique. Depending on the different density between hot water and cold water, the water flowing cycle is crated in the tube. Hot water flows automatically upwards while the cold water flows down. The water in the storage tank will be heated from this natural circulation.
Technical Parameters
Inner tank SUS 304-2B/0.41mm
Outer tank Galvanized steel/0.41mm
Insulation high density polyurethane foam 50mm
Vacuum tube 47*1500mm/58*1800mm, AL-N-AL coating
Bracket Galvanized steel 1.5mm 0-50 degree
Capacity: 100L 150L 200L 240L 300L(according to customers' requirement)
Remark
1. Inner tank and Outer tank diameter(mm): 360/460
2. Insulation thickness: 50mm
3. Vent connection(inch): 1/2
4. Electrical heating connection(mm): 47
5. Water connection(inch): 1/2 or 3/4
6. Assistank connection(inch): 1/2
| Type | Area
( m2 ) | Vacuum tube | Volume
(L) | Gross Weight
(KG) | 20GP/40GP/40HQ
Loading Qty(sets) |
Φ (mm) |
Length(mm) |
Qty(pcs) |
Shouting-NP02-10 |
1.979 |
58 |
1800 |
10 |
100 |
78 |
53/109/130 |
Shouting-NP02-12 |
2.142 |
58 |
1800 |
12 |
120 |
81 |
50/100/124 |
Shouting-NP02-15 |
2.382 |
58 |
1800 |
15 |
150 |
85 |
48/93/112 |
Shouting-NP02-20 |
2.651 |
58 |
1800 |
20 |
200 |
94 |
40/82/98 |
Shouting-NP02-24 |
2.958 |
58 |
1800 |
24 |
240 |
96 |
34/61/72 |
Shouting-NP02-25 |
3.189 |
58 |
1800 |
25 |
250 |
97 |
30/64/75 |
Shouting-NP02-30 |
3.995 |
58 |
1800 |
30 |
300 |
112 |
25/52/62 |
