Snowell Sea Water Ice Flake Maker Machine
| Price: |
US $ 29199/Set |
| Trade Terms: |
FOB |
| Min Order: |
1/Set |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
SFS5T-2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Snowell Sea Water Ice Flake Maker Machine |
| Ice Machine Compressor Brand: |
Bitzer/Bock |
| Flake Ice Maker Electrical Parts: |
Schneider |
| Power Supply: |
380V/50Hz/3p or Else |
| Refrigeration Capacity: |
38kw |
| Ice Machine Total Input: |
22.5kw |
| Power Of Reducer: |
0.37kw |
| Evaporator Structure: |
Spiralg Roove |
| Reducer Power: |
0.55kw |
| Ice Machinewarranty: |
2 Years |
| Ice Shape: |
Flake Ice |
| Certification: |
CE |
| Condition: |
New |
Product Description
Detailes Description:snowell Sea Water Ice Flake Maker MachineModel: SF5T-R4A
Flake Ice Maker Daily Capacity: 5000kg
Ice Machine Compressor: Bitzer/Bock
Cooling way: Water Cooled
Production Capacity Available: 1-30T Per Day
SNOWELL sea water flake ice maker machine has adopted the newest international ice machine making technology. We use and only use world famous components like Bitzer,Bock, Danfoss,Schneider and so on.
Compare to other supplier of sea water flake ice machinery in the industry, SNOWELL ICE SYSTEMS Owns its unique technology and get much more better performance.
Additional Specifications for the 5T on board sea water ice flake maker machine:
| NO. | Description | Specs. |
| 1 | Product Name | Snowell 5T/day sea water ice flake machine |
| 2 | Refrigeration capacity | 38 kW |
| 3 | Ice machine total input | 22.5 kW |
| 4 | Cooling mode | Water cooling |
| 5 | Evaporator structure | Spiral groove |
| 6 | Ice Machine Evaporating temp. | -32°C |
| 7 | Condensing temp. | 35°C |
| 8 | Flake ice temp. | -5°C |
| 9 | Thickness of flake ice | 1.5-2.2mm |
| 10 | Water feeding pressure | 0.1Mpa-0.5Mpa |
| 11 | Design ambient temp. | 25°C |
| 12 | Design water inlet temp. | 20°C |
1. Superb Stability and reliability, long use life of the sea water flake ice maker. 2. User-friendly design, intellectualized PLC touch-screen controller * The intellectualized PLC touch-screen control system, user-friendly designed, which is very convenient for operator. * The intellectualized historical failure record * Function and guidance of trouble shooting makes easier and simple operation and maintenance. * Running time setting function convenience operator, * Saving energy and reduce cost for the sea water flake ice maker machine 3. Sub-cooled ice, excellent fast cooling Super cold, dry, crisp, 100% sub cooled ice with greater surface area and exceptional cooling power. 4. Low maintenance and operation cost for the sea water flake ice maker machine Super performance offers trouble-free operation, with much less maintenance probability than other brands of ice flakers. 5. Energy-efficient and cost saving for the flake ice machineSnowell sea Water flake ice maker machine applications fields
1. Man-Made snow making project
2. Chemical Industry
3. Fishery. aquatic products processing and vegetables & fruits preservation
4. Food Fermentation
5. Meat, dairy products processing and the other food industries.
Flake Ice Features:
1. Directly formed at low temperatures, ice flakes are as cold as minus 5-8°C.
2. Ice Flakes are dry, powerless, and not like to lump.
3. Big contact area and good mobility ensure the full contact with refrigerated objects, like fish, concrete and so on.
4. No acute edges or Conner. No damage to fish skin or else.
After-sales Service
1. Two years warranty
2. Offer Spare parts free of charge within the warranty period.
3. Technical Documents
All Snowell ser water flake ice machines come out with 24 months full warranty. If the machine breaks down in 24 months, Snowell will send the parts for free, even send the technician over if situation needed. When beyond the warranty, Snowell will supply the parts and service only for factory price.
Company Profile
Shenzhen Snowell Refrigeration Equipment Co., Ltd is founded in May, 2006, with registration capital 25 million in US Dollar. As one 10 years experienced manufacturer of refrigeration equipments in China, SNOWELL has been dedicated into researching and developing refrigeration technology. We mainly design and manufacture ice flake machine, ice tube machine, ice block machine ect. Snowell products have passed CE, UL, ISO9001, ISO14000 certificate.
Frequent Asked Questions(FAQ)
Q1: What is the delivery time?
A1:
1).The ice making machine type. Our main product line includes Flake Ice Maker Machine, Tube Ice Maker Machine, and Block Ice Maker Machine. The manufacturing is totally different. So the time and effort spent on these machines varies. Normally the flake ice machine is fastest under the same ice daily capacity
2). Different Ice Daily Capacity: we have 1T, 2T, 5T, 10T, 20T, 25T, 30T, 40T, 50T ice making machines. For small capacity ice making machines(like1-5 tons), it needs about 10-15 working days. For larger capacity ice machines, it needs around 20-30 working days).
Q2. What is the payment terms and trade terms?
A2: Normally, we accept T/T, 30% Deposit and 70% balance paid before delivery.
Trade Terms: FOB Shenzhen
Q3: Do I need to install the ice machine by myself?
For small ice machine, we ship it as a whole unit. So you just need to prepare power and water to run the machine.
For some larger ice maker machine, we need to keep some components separate for shipping convenience. But no worries about that. An installation brochure will be sent to you, it's very to install the machine.
Q4: For Water Cooled and Air cooled Machine, Which one is better?
A4: It depends. If the electricity is more abundant and cheaper than water, air cooled one is recommended. Likewise, you can choose the water cooled one according to the situation.
And by the way, if you use it on the fishing boats, of course it's best using the water cooled type ice machine!
Shenzhen Snowell Refrigeration Equipment Co., Ltd is founded in May, 2006, with registration capital 25 million in US Dollar. As one experienced manufacturer of refrigeration equipments in China, SNOWELL has been dedicated into researching and developing refrigeration technology. We mainly design and manufacture ice flake machine, ice tube machine, ice cube machine, ice block machine, ice plate machine, water chiller, concrete cooling system, automatic ice storage system, dynamic ice storage system and all kinds of cold rooms.
Headquartered in Shenzhen, Snowell has 3 Industrial Parks. Marketing network has been extended to many domestic cities, such as Beijing, Shanghai, Guangzhou, Qingdao, Dalian and Wuhan, and abroad, such as Middle East, Southeast Asia, Europe, Australia, America, Africa and so on.
Snowell attracts numbers of excellent and professional talents and has scientific and research and talents cooperation with many Chinese famous colleges and universities. We have achieved several national patents and get the pressure vessel manufacture license. Snowell products have passed CE, UL, ISO9001, ISO14000 certificate.
After almost 10 years of development, Snowell has become the most competitive manufacturer of ice making system and other refrigeration equipments.
