Snowell Indutrial 3t Per Day Flake Ice Maker (SF3T-R4A)

Prod Model:	SF3T-R4A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Name:	Snowell Indutrial 3t Per Day Flake Ice Maker
Ice Maker Compressor Brand:	Bitzer/Bock From Germany
Ice Maker Electrical Parts:	Schneider
Power Supply:	380V/50Hz/3p or Else
Refrigeration Capacity:	18 Kw
Ice Maker Nominal Current:	18A
Total Input:	10.2kw
Ice Maker Evaporator Structure:	Spiralg Roove
Ice Maker Warranty:	24 Months
Thickness Of Flake Ice:	1.5-2.2tmm
Ice Shape:	Flake Ice
Certification:	CE
Condition:	New

Product Description

Detailed Description:

Snowell Indutrial 3T Per Day Flake Ice Maker(SF3T-R4A)


Fresh water ice flake maker application fileds.

1. Large concrete pouring project
2. Man-made snow making project
3. Chemical Industry
4. Fishery, aquatic products processing and vegetable & fruits preservation
5. Food Fermentation
6. Meat, dairy products processing and the other food industries


Ice Flake Maker Features

1. This is Freon System Flake Ice Maker

Freon (R507, R404A, R22) refrigerant is used in small or medium capacity flake ice machines.

2. Safety and sanitation

We use stainless steel, pure aluminium, alloy, and special treatment to prevent corrosion and make sure the flake ice machine is clean and safe to use in all industries. Anti-corrsion also extend the machine's service time.

3. High Relaibility and low breakdown rate.

Snowell flake ice maker  have adopted the newest international ice machine makig techology. We use and only use world famous components like Bitzer, Danfoss,Schneider and so on. According to our test, Snowell flake ice machine can produce quality ice and stand over  29,515 hours of constant operation without breakdown.

4. High efficiency and energy saving.

    We optimize the internally-scraping evaporator to make the ice falling reach 100%. We use a special kind of alloy material and patented processing technology to improve the thermal conductivity.


5. Simple installment, iperation and maintenance.

   Users just need to connect the system with water and power, press the button, ice comes out. Once some of the parts need to be replaced, it is easy for you to remove the old parts and install the new ones.


6. Great adaptability and stable quality.

Snowell products can ensure good running and normal ice out put at the ambient temperature from 5-40ºC. With our special-designed type, it can normal works in the most unfavorable working condition(-30 ºC to 60 ºC)

Details of 3T/24 hrs  Fresh Water Ice Flake Maker
No	Description	Specification
1	Design Capacity	3000Kg/24h
2	Refrigeration Capacity	18 KW
3	Refrigerant	R404A
4	Total Input	10.2KW
5	Power Supply	380V/50Hz/3P or else
6	Nominal Current	18A
7	Cooling Mode	Air Cooling/Water Cooling
8	Evaporator Structure	Spiral Groove
9	Evaporating Temp.	-22°C
10	Condensing Temp.	45°C
11	Flake Ice Temp.	-5°C
12	Thickness of Flake Ice	1.5-2.2mm
13	Water Feeding Pressure	0.1 Mpa--0.5Mpa
14	Design Water Inlet Temp.	25°C
15	Design Ambient Temp.	18°C
16	Unit Weight	550KG

Company Profile

Shenzhen Snowell Refrigeration Equipment Co., Ltd is founded in May, 2006, with registration capital 25 million in US Dollar. As one 10 years experienced manufacturer of refrigeration equipments in China, SNOWELL has been dedicated into researching and developing refrigeration technology. We mainly design and manufacture ice flake machine, ice tube machine, ice block machine ect. Snowell products have passed CE, UL, ISO9001, ISO14000 certificate.


Frequent Asked Questions(FAQ)

Q1: What is the delivery time?

A1:
   1).The ice making machine type. Our main product line includes Flake Ice Machine,Tube Ice Machine,Block Ice Machine. The manufacturing is totally different. So the time and affort spent on these machines varies. Normally the flake ice machine is fastest under the same ice daily capacity
   2). Different Ice Daily Capacity: we have 1T,2T,5T,10T,20T,25T,30T,40T,50T ice making machines. For small capacity ice making machines(like1-5 tons), it needs about 10-15 working days. For larger capacity ice machines, it needs around 20-30 working days).


Q2.: What is the payment terms and trder terms?

A2: Normally, we accept T/T,  30% Deposit and 70% balance paid before delivery.
      Trade Terms: FOB Shenzhen


Q3: Do I need to install the ice machine by myself?

For small ice machine, we ship it as a whole unit. So you just need to prepare power and water to run the machine.
For some larger ice machine plant, we need to keep some components seperate for shipping convenience. But no worris about that. An installation brochure will be sent to you,it's very easy to install the machine.

Q4: For Water Cooled and Air cooled Machine, Which one is better?

A4: It depends. If the electricity is more abundant and cheaper than water, air cooled one is recommended. Likewise, you can choose the water cooled one according to the situation.
