| Prod Model: |
DT5500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Access Controller, Attendance Machine |
| Type: |
Card |
Product Description
Product Name: Access control reader
Model: DT5500
Size: 88 × 88 × 10 (mm)
Color: Pearl White (White)
Operating voltage: DC 5 ~ 16V
Working current: ≤ 60mA
Working environment: -20 ~ 70
Sensing range: 3 ~ 15cm
Output formats: Wiegand26/34 the Rs485, Rs232
Card type: EM-ID/Mifare-IC
|
NUMBER |
COLOR |
SYMBOL |
DESCRIPTION of smart card reader interface |
|
1 |
Red |
VCC |
Positive Power Supply |
|
2 |
Black |
GND |
GND |
|
3 |
Green |
WD0(DATA) |
Wiegand Data 0 output or ABA output |
|
4 |
White |
WD1 (CLK) |
Wiegand Data 1 output or ABA CLK output |
|
5 |
Blue |
LED |
LED |
|
6 |
Yellow |
BUZ |
BUZZER |
AOPU specializes in providing professional multi door access control systems. AOPU products are geared to all needs, from the office buildings, housing estates to multiple-site high tech corporations, universities, banks, police stations and prisions etc. Our products include: RS485 network single-door access controller, RS485 network multi-door (2 doors and 4 doors) access controller; TCP/IP network single-door access controller, TCP/IP network multi-door (2 doors and 4 doors) access controller; Access control software; Access control and time attendance administration system; RS485/232 access control converter; RF IC and ID card reader etc.
Our goal is to provide right and quality products with most friendly software.
Future: We do think that muliti door access controler have a hugh future. And AOPU will also follow the times' progress and develop more products meeting customer demand.
