| Prod Model: |
CNB-200 |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Installation: |
Internal |
| Card Slots: |
Single |
| Interface: |
Wg26 Output |
| Type: |
Magstripe Card |
| Capacity: |
Chipset |
Product Description
Main technology parametric
Power supply DC12V
Electric lock permit maximum output current 3A(12V)
Static power consumption 22mA
Perating current 40mA (non-current electric lock)
Unlock time adjustable 1~10s
Unlock and open the door automatically with the time difference 0.5s
Magnetic card standards ISO7811-7815
Permit card speed 10~120cm/s
Head life expectancy >=600000times
Working ambient temperature -42~45
Working environment humidity 10~90%RH
Overall dimension 138mm(L)x56mm(W)x32mm(H)
Total weight 400g
AOPU specializes in providing professional multi door access control systems. AOPU products are geared to all needs, from the office buildings, housing estates to multiple-site high tech corporations, universities, banks, police stations and prisions etc. Our products include: RS485 network single-door access controller, RS485 network multi-door (2 doors and 4 doors) access controller; TCP/IP network single-door access controller, TCP/IP network multi-door (2 doors and 4 doors) access controller; Access control software; Access control and time attendance administration system; RS485/232 access control converter; RF IC and ID card reader etc.
Our goal is to provide right and quality products with most friendly software.
Future: We do think that muliti door access controler have a hugh future. And AOPU will also follow the times' progress and develop more products meeting customer demand.
