Shenzhen Yilong Led Display Co., Ltd. >> Single Color LED Display/P10 Outdoor Single Color LED Display

Single Color LED Display/P10 Outdoor Single Color LED Display

Single Color LED Display/P10 Outdoor Single Color LED Display
Price: US $ 260.87/Square Meter
Trade Terms: EXW
Min Order: 1/Square Meter
Pay Type: T/T
Prod Model: p10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 320mm*160mm
Module Resolution: 32*16
Module Weight: 0.75kg
Brightness: 1800CD/M2
Waterproof: IP65
Pixel: 1r
Piexl Density: 10000
Tube Chip Color: Single Color
IP Rating: IP65
Pixel Pitch: 10mm
Display Function: Text Display
Scanning Mode: 1/4 Scan
Certification: FCC
Pixel Density: 10000 dot / m²
Average Power Consumption: 180W / m²
Pixel Configuration: 1r

Product Description

Type: PH10
Pixel pitch(mm): 10
Pixel density(DOT/m² ): 10000
Pixel specification: 1R
View degree: 110
Module size: 320mm*160mm
Module resolution(DOT * DOT): 32*16
Module number / cabinet: Depend on cabinet size
Grey level(level): 256
Refresh rate(Hz)>380
Brightness(CD/)≥ 1500
Weight(kg/m² ): 30
Visual distance(m): >10
Power(w/)Max: 600
Average value: 180/m²
Drive mode1/4 scanning, Constant-current drive
Blind spot rate: ≤ 0.0003
Lifetime: 50000 hours
Working voltage (V): 220∨ /110V± 15%
Working temperature: (º C)-20º C~60º C
Working humidity: (RH)10%~90%RH
Control mode Synchronous control
Control systemPCTV card +DVI display card+ main control card +fiber transfer
SoftwareLED by studio or the user
Computer WINXP/WIN2000/WIN98 etc.
Display cardDVI
Control distance Twisted-pair 100m, Fiber ≥ 500m
Shenzhen Yilong LED display Co., Ltd.Is specialized manufacturer in LED display and LED lightings, which was founded in year 2006.Yilong intergrates designing, manufacturing, sales, engineering services also after services.The quality system management ISO9001 and with many facilities as high-speed fully automated SMT machine, fully automated glue-pouring machine, reflow ovens, wave-soldering, also engineers with rich experience and skilled workers.

With an excellent quality and services, Yilong has owned rich customers'reputations both from China also from other countries in the world as Taiwan, Hong Kong, Singapore, USA, South-Africa, etc…Our main products include LED display screen single color, bi-color and full color and various modules.

Importers, buyers, distributors, wholesalers, retailers, agencies, representations, trade, suppliers, vendors are all sincerely welcomed to join Yilong will be the best partner to your further successful business.
