| Prod Model: |
p5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
160mm*160mm |
| Module Resolution: |
32*32 |
| Module Weight: |
0.75kg |
| Pixel: |
1r1g1b |
| Brightness: |
2000CD/M2 |
| Light: |
SMD Three in One |
| LED Light: |
Taiwan Epistar |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/16 Scan |
| Certification: |
RoHS |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
5mm |
| Application: |
Shopping Guide |
| System Operating Platform: |
WIN XP |
| IP Rating: |
Depend on Customer Demand |
Product Description
Type pH5
Pixel pitch(mm) 5mm
Pixel density(DOT/m² ) 40000
Pixel specification 1R1G1B
View degree 120°
Module size(mm) 160mm*160mm
Module resolution(DOT *DOT) 32*32
Module number Depend on cabinet size
Grey level 4096
Refresh rate (Hz) 380Hz
Brightness(CD/m² ) ≥ 2000
Weight(Kg/m² ) 24
Display color 167772
Visual distance(m) 4m
Max power consumption: 800 w
Drive mode 1/8 scanning. Constant-current drive
Blind spot rate ≤ 0.0003
Working voltage AC220V/110V± 15%
Working Environment Temperature (º C): 20º C~60º C
Working Environment Humidity(RH): 10%~90%RH
Control modeSynchronous control
Lifetime: 50000hours
Software: LED by studio
Shenzhen Yilong LED display Co., Ltd.Is specialized manufacturer in LED display and LED lightings, which was founded in year 2006.Yilong intergrates designing, manufacturing, sales, engineering services also after services.The quality system management ISO9001 and with many facilities as high-speed fully automated SMT machine, fully automated glue-pouring machine, reflow ovens, wave-soldering, also engineers with rich experience and skilled workers.
With an excellent quality and services, Yilong has owned rich customers'reputations both from China also from other countries in the world as Taiwan, Hong Kong, Singapore, USA, South-Africa, etc…Our main products include LED display screen single color, bi-color and full color and various modules.
Importers, buyers, distributors, wholesalers, retailers, agencies, representations, trade, suppliers, vendors are all sincerely welcomed to join Yilong will be the best partner to your further successful business.
