| Prod Model: |
SGDLCM1906A301(1.1t, normal temp. ) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Driving Conditions: |
1/64duty 1/9bias |
| Connection Mode: |
COB |
| Display Mode: |
Transflective/Positive |
| Operating Temperature: |
0~50 C Degrees |
| Storage Temperature: |
-10~60 C Degrees |
| Screen Size: |
≤17" |
| Application: |
Graphic Design |
| Aspect Ratio: |
16:10 |
| Type: |
STN |
| Widescreen: |
Not Widescreen |
| Response Time: |
30ms |
| 3D: |
Not 3D |
| Feature: |
No Touch Panel |
| Optimum Resolution: |
192*64 |
| Interface Type: |
COB |
Product Description
Display Color positive/Transflective
Delivery Term:45 days
Display mode:STN/yellow-green
The thickness of single glass:1.1t
Connector type:Zebra
Driveing Method:1/64duty 1/9Bias
| Viewing direction | 6 O'CLOK |
| Module Size | 112.46(W)*50.46(H)*4.0(T) |
| Viewing area | 108.46Min(W)*41.46Min(H) |
| Resolution | 192*64 |
| Effective display area | 103.46(W)*35.46(H) |
| Dot size | 0.34(W)*0.362(H) |
| Dot Pitch | 0.54(W)*0.562(H) |
| Driving voltage of LCD | 11.8V |
