| Prod Model: |
GM-04K |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
for Refrigerate |
| Certification: |
CE |
| Cooling Method: |
Direct Cooling |
Product Description
Standard condition: Ambient temperature 25, water temperature16º CThe above-mentioned parameter will be changed subject to technical invovation without further notice.
Refrigeration units: The main accessories are imported from U. S. A. \German\Japan. Which remains good reliability and makes the system perfect performance and energy-saving.
Technical Innovation - PLC programmable control system
Since the year of 2008, ICESNOW microcomputer control system was changed to PLC programmable control system, to enhance the stability of the system and runs more convenient.
PLC programmable control system, that is the PLC programmable logic controller through the ice-making unit to open, stop automatic control, so that ice cylinder operating system and water circulation system coordinated match, to be safe and efficient operation. When the unit fails, PLC automatic shutdown protection, and the input point of fault indicator displays on the status, when the failure recovery, PLC unit receives information and automatically start to realize a full automatic control.
Cylinder: With the horizontal motional design, the wear-out of the system can be reduced, and gas leak avoided. It is also maintaining good precision and intensity with High grade 304 stainless steel together automatic argon-arc welding.
Ice Skates is a screw scraper, features low resistance, low consumption, no noise.
Application Industries: Supermarket fresh, hotels chilled, vegetables distribution and preservation, Biopharmacy, laboratory refrigeration
|
Model |
daily output (kg/24h) |
Bin capacity |
Ref.capacity(kcal/h) |
Evaporating Temperature |
Total power (kW) |
Power supply |
Re-frigeration |
|
(kg) |
|
GM-04K |
400 |
300 |
1880 |
-20ºC |
2.7 |
3p/380v/50Hz |
R404A |
|
Flake ice thickness(mm |
Cooling mode |
Unit dimension |
Bin size |
Weight(exclude bin) |
|
L*W*D(mm) |
L*W*D(mm) |
(kg) |
|
1.8-2.5 |
air cooling |
1235*740*780 |
1280*1050*1060 |
205 |
Shenzhen Icesnow Refrigeration Equipment Co., Ltd. is a high-tech enterprise and professional manufacturer of refrigeration equipment and system which specialized in researching, designing, producing and trading of industrial and commercial refrigeration technology and facilities of ice flake machine. The company owns the first-class equipment, advanced manufacturing workmanship and complete testing method as well as modern management mode. Now we have launched 3 series ice flake machines covering 16 types, with its daily output ranging from 400kgs to 50ton, which greatly satisfied the increasing demands on the commercial ice and industrial ice. Our products are widely used in hyper market freshing, food processing, ocean fishery, Chemicals and dyeing, bio-pharmacy and laboratories.
Icesnow ice system, with its main parts imported abroad, is elaborately designed and has a superior performance. For the whole system is automatically controlled by microcomputer, so it's extremely easy and simple for operation. And the bin cylinder is our patented product, which ranks a leading level and gains widely reputation in and abroad.
First-class products, continuous innovation, durative improvement and clients satisfaction is our tenet. Excellent quality product, complete service and reasonable price is our persistent principle to hold market. We believe our sincerity and seeking-better altitude deserves your trust.
