| Prod Model: |
BT-100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Speaker System: |
2.0 Channel |
| Application: |
Commercial |
| Operation Mode: |
Knob Control |
| Hi-Fi: |
Not Hi-Fi |
| Speaker Material: |
Metal |
| Monitor: |
LED Screen |
| THD: |
<0.005% |
| Noise: |
<95dB |
| Certification: |
CE |
Product Description
FEATURES:
Constant voltage, constant resistance output , preamplifier and sound source mixed function
2 lines aux input and 1 line aux output and have independent volume adjust function
3 lines Mic input, have independent volume adjust function. The first line Mic has force mute function, the first line also have three phantom power mode---48v phantom power, 12v phantom power, can choose different capacity Mic, also can use common Mic input the first line
high and low volume tone control
MP3, SD, MMC/MS, FM radio and Bluetooth function. The functions could be adjusted through remote, also these functions could adjust the volume independently
4--16Ω constant resistance output, 70v,100v constant voltage output
Temperature, DC, overload and short current protection
Model
BT-50
BT-100
Output Power
50w
100w
Output mode
4-16Ω constant resistance output, 70v, 100v constant voltage
Mic input
Mic1: 600Ω, 4mv, unbalance
Mic1: 600Ω, 4mv, unbalance
+48v, +12v phantom Mic, common Mic
Aux input
Aux1: 10kΩ,470mv. unbalance
Aux2: 10kΩ,470mv. unbalance
Frequency response
250Hz-16kHz(3dB)
Nolinear distortion THD
<0.5% at 1khz, 1/3 rated output power
S/N
>75dB
Volume Range
Bass:100hz(15dB), Treble:12Khz(15dB)
Output range
3dB from no signal static state to full load state
Function control
Volume buttons 6, high&low volume 2, power switch 1
Cooling Mode
DC12V force wind cooling
Cable
(3 0.75mm2 ) 1.5M ( American)
Power AC
AC220V 10%, 50-60Hz
Dimension
337x343x66mm
RUNFENG AUDIO" is a China based PRO amplifier MANUFACTURER that mainly offers OEM/ODM business for contractors, installers, professinals and all kinds of sound companies all over the world. We have been released RUNFENG DESIGNS to partners both in China and oversea for decades.
The founder, Mr Paul Lin, who started his carear with his strong desire and passion to PRO amplifier and relative audio equipments. He spent most his time and energy to design and research how to make PRO amplifier work. His works has come out and helped many professionals with a high quality but low burget solutions. But he doesn't even stop working hard his research for a better solution.
RUNFENG AUDIO was founded to overtake next revolution of the future, located in Zhongshan city Guangdong province. With clear MOTTO"QUALITY FIRSTLY". We decide to devote ourself to a single line of AUDIO PRODUCTS.
