| Prod Model: |
CS068A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Backlight: |
LED |
| Brightness: |
250CD/M2 |
| Color Standard: |
PAL/NTSC Auto |
| Contrast: |
300:1 |
| Screen: |
TFT LCD Screen |
| View Angle: |
U:50/D:70 L/R:70/70 |
| Light Source: |
LED |
| Color System: |
PAL/NTSC |
| Power Supply: |
DC 12V |
| Power Consumption: |
Less Than 5 W |
| Definition: |
420TVL |
Product Description
Specifications
1.Plastic case, metal structure
2.Automatically switch to the rear-view camera when reversing
Technical information:
| Item | Specification |
| Screen Size | 5.6 inch |
| Screen | TFT LCD screen |
| Screen Ratio | 4: 3 |
| Resolution | 960(H)×234(V) |
| Contrast | 300:1 |
| Brightness | 250cd/ m2 |
| View Angle | U:50/D:70 L/R:70/70 |
| Light Source | LED |
| Color System | PAL/NTSC |
| Video Input | 1VP-P 75Ω (two way) |
| Image Inversion | U/D L/R;manual(optional) |
| Interface | RCA, Aviation plug |
| Power Supply | DC 12V |
| Product Dimension | 155mm (L)×135mm (W)×29.5mm (H) |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~85 |
| Power Consumption | less than 5 W |
Standard Fitting:
1.Bracket
2.Remote controller
3.DC24V to DC12V adapter
4. Cable
5.User manual
Description:
1.3-CH video input,can be switched by key-press
2.Automatically switch to the rear-view camera when reversing
3.Wide range of power supply
4.Brightness, contrast and chroma can be adjusted by key-press
5.Isolated power supply,hight anti-interference
6.Vehicle disturb shielding line and RS765-4plug for signal transmit
