| Prod Model: |
Sanway FP10000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension(Lxwxh): |
483X88X396mm |
| Operating Voltage: |
130-265 V / 65-135 V Selectable |
| Type: |
Professional Amplifier |
| Function: |
Amplifier Combined |
| Tube Type: |
Transistor Amplifier |
| Voltage: |
AC 110V |
| Element Number: |
Push-Pull Amplifier |
| Output Number: |
4 |
| Used For: |
Professional |
| Conductive Mode: |
B |
| Usage: |
KTV System |
| Sound Channel: |
4.1 |
Product Description
Professional Power Multi-Functional Amplifier (FP10000Q)
1.4X2500W@2ohm Tube Power Amplifier Pro Audio
2. Lightweight 13kg Switching Power Amplifier
3. FP10000Q High Power White Front Panel Power Amplifier
4. Professional Show Power Amplifier
5. Pro Audio Power Amplifier FP10000Q
Key Feature
1) Minimum power-to-weight ratio
2) Minimum power-to-volume ratio
3) Zero heat insulation cooling system
4) Segmented analysis on system temperature
5) Transistors line-up at zero thermal path difference
6) Cumulative analysis on high frequency power
7) Accurate power dispatching
8) Real-time / Online detecting of load resistance
9) Dynamic adjusting and analysis on the integrated output
10) Complete 4-channel, 2U amplifier series
11) Maximum output power up to 4x1350W@8ohms
12) Refined SMD production technology
13) All-round circuit soft protection without anintemal circuit break
14) S/N ratio more than 112dB even higher
15) High damper factor over 800
16) High slew rate as high as 100V/us
17) 2.66 ohm parallel, low impedance loading
|
FP1000Q 4CH Professional Digital Powered Amplifier, Top PA Speakers Amplifier |
|
ITEM |
FP10000Q |
|
Output Power |
20-20kHz, 1W with 1 KHz |
|
8Ω Stereo Power(RMS) |
1350WX4 |
|
4Ω Stereo Power(RMS) |
2100WX4 |
|
2Ω Stereo Power(RMS) |
2500WX4 |
|
8Ω Bridged Power(RMS) |
4200WX2 |
|
4Ω Bridged Power(RMS) |
5000WX2 |
|
Frequency Response(+o/-0.3dB, 1W/8Ω ) |
20 Hz - 34 kHz |
|
THD 20 Hz - 20 kHz for 1 W |
< 0.1% |
|
Signal-to-Noise Ratio |
> 112 Dba |
|
Channel separation (Crosstalk) at 1 kHz |
> 70 dB |
|
Input Connectors (per channel) |
3-pin XLR, electronically balanced |
|
Output Connectors (per channel) |
Binding Posts 2-pole |
|
Class |
TD |
|
TourClass Protection |
short circuit, DC voltage, turn-on/off transient, current, inrush |
|
Operating voltage |
130-265 V / 65-135 V selectable |
|
Voltage Gain(dB) |
23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
|
Input impedance |
20 Kohms |
|
Level adjustment (per ch. ) |
Front-panel potentiometer, 31 position detented from -inf to 0 dB |
|
Dimensions (W× H× D) |
483× 88× 396mm |
|
Packing dimension |
580× 180× 560mm |
|
Net weight(kg) |
13 |
|
Gross weight(kg) |
18 |
