| Prod Model: |
Sanway PA08 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency Response(+O/-0.3db, 1W/8ohms ): |
20Hz-20kHz, -3db@135kHz |
| Usage: |
KTV System |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Function: |
Amplifier Combined |
| Sound Channel: |
2.1 |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
3 Step H Class |
Product Description
Professional Power Amplifier, Audio Power Amplifiers (PA08)
1) Minimum power-to-weight ratio
2) Minimum power-to-volume ratio
3) Zero heat insulation cooling system
4) Segmented analysis on system temperature
5) Transistors line-up at zero thermal path difference
6) Cumulative analysis on high frequency power
7) Accurate power dispatching
8) Real-time / Online detecting of load resistance
9) Dynamic adjusting and analysis on the integrated output
10) Complete 2-channel, 2U amplifier series
11) Maximum output power up to 1500W@8ohms
12) Refined SMD production technology
13) All-round circuit soft protection without anintemal circuit break
14) S/N ratio more than 110dB even higher
15) High damper factor over 1500
16) High slew rate as high as 100V/us
17) 1 ohm parallel, low impedance loading.
| PA08 Lightweight Power Amplifier |
| 8Ω Stereo Power(RMS) | 2 × 800W |
| 4Ω Stereo Power(RMS) | 2 × 1200W |
| 2Ω Stereo Power(RMS) | 2 × 1600W |
| 8Ω Bridged Power(RMS) | 2400W |
| 4Ω Bridged Power(RMS) | 3200W |
| 2Ω Parallel Power(RMS) | 2400W |
| 1Ω Parallel Power(RMS) | 3600W |
| Frequency Response(+o/-0.3dB, 1W/8Ω ) | 20Hz-20kHz, -3dB@135kHz |
| Phase Response ( at rated power 20Hz-20kHz) | < +/-8 degree |
| THD+N (at rated power 1kHz 1W ) | < 0.025% |
| SMPTE IMD (rated power. 60 Hz/7kHz-1/4) | < 0.075% |
| Damping Factor ( at rated power 63Hz) | > 1500 |
| Controlled Slew Rate ( 1kHz tone burst 40dB gain) | > -100v/us |
| Voltage Gain ( 0.775V/0dBm ) | X103 |
| Input Sensitivity ( X40/36dB ) | 2.00V |
| S/N Ratio (" A" weighted, 1kHz, 1V input ) | > 110dB |
| Max Output Voltage(40millisecond tone burst) | 141V |
| Power Current Draw (typical music) | 1000VA/4.3A |
| Power Current Draw (over loading) | 2000VA/8.7A |
| Input Connectors (per channel) | Female XLR (pin 2+, configurable for pin 3+). TRS (tip+) |
| Output Connectors (per channel) | 5-way binding posts or Speakon connectors (market dependent) |
| Power Supply (factory configured) | AC220V/230V, 50-60Hz |
| LED Indicators (per channel) | Signal, Protect, Active, Critical |
| Construction | Steel chassis, 16 gauge. Casting Aluminum front |
| Dimension | 88X482X400mm |
| Net Weight | 16.5kg |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
