pH8 Outdoor Die-Casting LED Display
| Price: |
US $ 1567/Square Meter |
| Trade Terms: |
FOB,EXW |
| Min Order: |
1/Box |
| Pay Type: |
T/T,Paypal,Western Union |
| Prod Model: |
PH8 black lamp SMD3535 die-casting led display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
320*160mm |
| Cabinet Size: |
640*640*100mm |
| Brightness: |
More Than 5000 CD/Sqm |
| Protection Level: |
IP65(Front) / IP54(Back) |
| Cabinet Material: |
Die-Casting |
| Warranty: |
2 Years |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Certification: |
CCC |
| Display Function: |
Video Display |
| Application: |
Stage Performance |
| Scanning Mode: |
1/4 Scan |
| Average Power Consumption: |
300W / m² |
| Pixel Pitch: |
8mm |
| Pixel Density: |
15625dots/Sqm |
Product Description
Outdoor SMD die casting rental LED display screen is super thin (100mm depth) and super light (14kg/cabinet). It is very convenient for installatioin and transportation, and it can be simply assembled and disassembled by only one people.
| Fast and Easy Installation
Die casting aluminum cabinet, light weight, slim depth, fast locks guarantee the fast and easy installation & dismantle. |
|---|
| | Slim Depth
Depth of the cabinet is only 100mm, take small space, which is great convenient for rental and transportation. |
|---|
| | Light Weight
Weight of each cabinet is only 14kg, only one people can easily install and move it. It saves man power. |
|---|
| | Professional-grade Connectors
LEDA rental cabinets use professional grade connectors for fast installation, safe and stable connection. |
|---|
| | High Refresh Rate
The refresh rate is more than 1000HZ, it is flicker-free when live broadcast. It fully meets the needs of professional camera shooting. |
|---|
| | IP65 Water Proof
The cabinet is IP65 water-proof, it is all weather designed. |
|---|
| | Independently Removable and Replaceable
You can change any parts freely without removal of other products, the failure can be super fast solved. |
|---|
| | Wide Viewing Angle
Horizontal and vertical viewing angle is 140 degrees, pictures and videos of the display can be viewed by more viewers. |
|---|
| | Brightness Adjustable
The brightness can be adjusted automatically, it saves power cost. |
|---|
| | No Fan Design
No fan design guarantees silent operation. |
|---|
| | Fast and Easy to Maintain
The power and signal working status were showed, convenient for you to check out problem at the first time. |
|---|
| | Quality Guaranteed
The product is designed and produced in strict compliance with international standards, such as CE, ROHS. |
|---|
| Model | P8 |
|---|
| Model No.: | LEDA-OR-P8 |
|---|
| Pixel Pitch | 8mm |
|---|
| LED Type | SMD3535 |
|---|
| Pixel Configuration | 1R1G1B |
|---|
| LED Driving Method | 1/4 Scan |
|---|
| Module Pixel | 40*20 (W*H) |
|---|
| Module Size | 320*160MM |
|---|
| Cabinet Pixel | 80*80 (W*H) |
|---|
| Cabinet Size | 640*640*100MM |
|---|
| Iron Cabinet Weight | 14KG |
|---|
| Max. Power Consumption | ≤1000W/ |
|---|
| Ave. Power Consumption | ≤300W/ |
|---|
| Hor. Viewing Angle | 140° |
|---|
| Verti. Viewing Angle | 140° |
|---|
| Brightness | ≥5000 cd/ |
|---|
| Pixel Density | 15625/ |
|---|
| Protection Level | IP65(Front) / IP54(Back) |
|---|
| Processing | 16 bit |
|---|
| Colors | 281 trillion |
|---|
| Refresh Rate | ≥1000HZ |
|---|
| Frame Rate | 60fps |
|---|
| Lifetime | 100,000 Hours |
|---|
| Power | AC220/110 ± 10%, 47~63Hz |
|---|
| Operating Temperature | -20ºC to +60ºC |
|---|
| Operating Humidity | 20% to 90% |
|---|
| Brightness Level | Manual 100 levels,automatically 16 levels |
|---|
| Certifications | CCC, FCC, CE, ROHS, UL, ETL |
|---|
