| Prod Model: |
3.84mm, 4.8mm, 5.33mm, 6mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
6mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
27,777 dots / m² |
| Scanning Mode: |
1/8 Scan |
| Display Type: |
LED Video Display |
| Application: |
Shopping Guide |
| IP Rating: |
IP43 |
| Certification: |
CCC |
Product Description
P6mm fixed Screen Indoor Full Color LED Display Screen
Indoor Full Color LED Display Screen's Key Feature
1. Super Slim and lightweight
2. Aluminum structure, seamless splicing
3. Quick lock system, easy to install
4. High refresh rate and high contrast
5. Wide Viewing angle
6. Working status indicator
7. Application: Rental / Fixed
This 480x480mm Cabinet can be widely used to assemble large LED screens as request. To suit for many big event and stage application, and some indoor fixed application like shoping mall, department store etc.
| Model | PH6 |
| Pixel Pitch | 6mm |
| Unit Size | 480mmx480mmx70mm |
| LED Type | SMD 3528/black body or black face for choice |
| Pixel / Unit | 80x80 |
| Unit Weight | 7.5kg |
| Viewing Angle | H160 degree V100 degree |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level | For indoor use only |
| Power Consumption | 150W/panel Max |
| 70W/Panel Ave. |
| Driving | 1/8 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | 600Hz~2000Hz |
| Processing | 16bit |
| Max Brightness | 1,500nits |
| Power Supply | AC90-240V, 50~60Hz |
| MTBF | ≥ 1, 000 Hours |
| Life Span | ≥ 50, 000 Hours |
| Pixel Failure | < 0.0003 |
We are a full range manufacturer and LED display solution provider and its ancillary systems worldwide since 2009, headquartered in Shenzhen with a 6000 square meter Production state of the art facilities to cover international demands. We provide a one-stop shopping in the design, production, and distribution of LED display and solution for our domestic and global clients.
Our products Cover indoor, outdoor, fixed, rental and creative LED Solutions for various applications including sport, advertisement, concert, shopping mall, stadium, exhibition or any other indoor and outdoor events that comes to your imagination.
We strictly follow ISO9001: 2008 quality management system and passed CE, FCC, UL, RoHS, CCC etc. All of these factors ensure high quality LED products and effective services.
