| Prod Model: |
p12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
320mm*160mm |
| Module Resolution: |
16*8 |
| LED Light: |
Taiwan Epistar |
| Pixel: |
2r1g1b/1r1g1b |
| Density: |
2500DOT/M2 |
| Brightness: |
4200CD/M2 |
| Module Weight: |
0.75kg |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Pixel Pitch: |
12mm |
| Display Function: |
Video Display |
| Scanning Mode: |
Static Scan |
| Certification: |
FCC |
| Average Power Consumption: |
220W / m² |
| Pixel Density: |
2500DOT/M2 |
Product Description
Type pH12
Pixel pitch(mm) 12mm
Pixel density(DOT/m² ) 6944
Pixel specification 1R1G1B
View degree 110
Module size 192mm*192mm
Module resolution(DOT * DOT)16*8
Module number / cabinet: Depend on cabinet size
Grey level(level) 4096
Refresh rate(Hz) >380
Brightness(CD/m² ) ≥ 5000
Weight(kg/m2) 35
Display color(color) 16777216
Visual distance(m) >12
Power(w/m2)Max: 640W
Average value: 280W
Drive mode: Static scanning: Constant-current drive
Blind spot rate ≤ 0.0003
Lifetime 50000 hours
Working voltage (V) 110V/220∨ ± 15%
Working temperature (º C) -20º C~60º C
Working humidity (RH) 10%~90%RH
Control mode Synchronous control
Control system PCTV card +DVI display card+ main control card +fiber transfer
Software LED by studio or the user
Computer WINXP/WIN2000/WIN98 etc.
Display card DVI
Control distance Twisted-pair 100m, Fiber ≥ 500m
Shenzhen Yilong LED display Co., Ltd.Is specialized manufacturer in LED display and LED lightings, which was founded in year 2006.Yilong intergrates designing, manufacturing, sales, engineering services also after services.The quality system management ISO9001 and with many facilities as high-speed fully automated SMT machine, fully automated glue-pouring machine, reflow ovens, wave-soldering, also engineers with rich experience and skilled workers.
With an excellent quality and services, Yilong has owned rich customers'reputations both from China also from other countries in the world as Taiwan, Hong Kong, Singapore, USA, South-Africa, etc…Our main products include LED display screen single color, bi-color and full color and various modules.
Importers, buyers, distributors, wholesalers, retailers, agencies, representations, trade, suppliers, vendors are all sincerely welcomed to join Yilong will be the best partner to your further successful business.
