Brilliantopto Co., Limited >> P10 Full Color LED Video Display

P10 Full Color LED Video Display

P10 Full Color LED Video Display
Price: US $ 645-685/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
Prod Model: JC-P10-FCO-RGB-01
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No.: P10
DOT Pitch: 10mm
LED Chip Spec: DIP346
Full White Brightness: >5500 CD Per Square Meter
Resolution: 32* 16dots 10000 Dots/Sqm
Certifications: CE, RoHS, FC, 3c, ISO9001
Function: Video, Animation, Graphics
Original: Southern Fujian China
Lifetime: Excellent with 10,000 Mtbf
Exporting: Asia, America, Europe etc
Display Type: LED Video Display
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Certification: FCC, ISO9001:2008
Pixel Pitch: 10mm
Display Function: Video Display
Scanning Mode: 1/4 Scan
Pixel Density: 10000 dot / m²
Average Power Consumption: 375

Product Description

Brilliantopto - P10 Full Color Led Video Display

Pixel Pitch: 10mm
Pixel Density: 10000 Dots/m2
Tube Chip Color: 1R1G1B
Led Chip Spec: DIP346
Module Size: (W)32dots× (H)16 dots
Int. Protection: IP65/IP54

Best View Distance: 10~150m
Viewing Angle(H): 120 Degree
Viewing Angle(V): 90 Degree
Working Temp: -20C~ +50C
Environment Temp: -40C ~ +85C
Operating Humidity: ≤ 90~95%

Module Weight: About 830g/pc
Operating Voltage: 220V± 5%
Average Power: 375W/m2
Maximum Power: 635W/m2
-------------------------------

Brilliantopto - About Us

Brilliantopto specializes in manufacturing led displays in Quanzhou Fujian,
Close to Xiamen port.
You can get the following products from us:

P3/ P4/ P5/ P6...Indoor full color led display
P10/ P12/ P12.5/ P16/ P20/ P25...Outdoor full color led display
Indoor/ outdoor/ semi-outdoor single/dual color led display etc.
-------------------------------

Brilliantopto - Guarantee

1) Our products are the CE certified, ROHS compliant, FCC identified.
2) Passing the system of ISO 9001 with IP65.
3) Free training is provided for our customers.
4) 1-year quality guarantee.
-----------------------------

Brilliantopto - Features

1). Good price
Our price is 10% lower than the market because of the introduction of full
Automatic production line with the characteristics of reducing the cost of
Labor and management.
2). Lightweight
Aluminum cabinet greatly saving fright cost and conveniently installing.
3). Stable performance
Our most basic guarantee: The aging time exceeding 24 hours. Malfunction
Dot rate less than 0.0001. MTBF more than 1000 hours.

4). Best quality LED chip tube
The GREE, SILAN, OPTO, EPISTAR assuring high brightness and long lifespan.
5). Supporting different formats of images and videos
Flash, WAV/MIDI, Videos from TV and other equipments.
6). Quality insured by CPIC and 1-year QA.
-------------------------------------------------

Brilliantopto - Payment and shipment

1) 30% deposit before production and balance paid before shipment.
2) Carton package, wooden case, flight case and customized package.
3) Shipment by express, by sea or by air within 10 working days.
                                                            P10 Full Color Led Video Display
ItemsP10
Pixel Pitch10mm
Module Size320mm*160mm
Dot Density10000 dots/sqm
Tube Chip Color1R1G1B
Module Resolution32*16


Red Wavelength625±5nm
Green Wavelength525±5nm
Blue Wavelength470±5nm
Viewing Angle (H)160°
Viewing Angle (V)110°
Display Brightness>6800 cd/sqm
Power ConsumptionMax. below 750W


Gray Scale> 4096
Driving Mode1/4, constant current
Control ModeSynchronization
Frame Frequency60Hz
Refresh Frequency  > 300Hz


IP GradeIP65
Operate Environment-20°C±50°C
Working Voltage Range220V±10%
Mean Time Between Failure> 10,000 hours
Led Display Working Lifespan> 100,000 hours

Brilliantopto Co., Limited Was founded in 2005, with a registered capital of 20.18 million Yuan, a workshop covering an area of 20000 square meters and independent living and production places. Our company is professional in the development and manufacture of LED display systems. Our company technology strength is among the front row in this area, with a vigorous team.

In March, 2011, our company independently researched and developed a full-color formal P16 LED display, which can completely replace the current market single color LED displays, being the perfect choice in the next line of LED display market. In June, 2011, after designing P10 optical modules, we ceremoniously rolled out P10 light module series, which can effectively enhance the efficacy by above 10% and can effectively avoid a screen phenomenon. In August, 2011, our company took the lead in Quanzhou LED industry technology innovation strategy alliance. As the President unit, our company set up "Quanzhou LED Technology Research Center", featuring the national quality supervision center. Our company has many experts and professors from Xiamen University Semiconductor Research Center, Fuzhou University and Beijing University Institute of Photoelectricity for our research center technology consultation to comprehensively promote Quanzhou LED industry. In November, 2011, relying on our strong technical research and development team, we made a new generation of international leading 3D display screens.

Through six years of unremitting efforts, our company has successively obtained such honorary titles as The State Ministry Of Small-Sized And Medium-Sized Enterprise Technology Innovation Fund Project Unit, Small-Sized And Medium-Sized Enterprise In Fujian Province Technology Innovation Fund Project Unit, ISO9001 International Quality Management System Authentication Enterprise, CCC China National Mandatory Product Certification Enterprise, CE Compulsory Product Certification Enterprise, FCC Anti-Radiation Product Authentication Enterprise, RoHS Lead-Free Environmental Protection Product Authentication Enterprise, IP65 Waterproof and Dustproof Product Authentication Enterprise, Chinese Optical Optoelectronic Industry Member Unit, National Taxpayer Service Work Outstanding Member Unit, Unit With 15 Independent Research And Development Patents Of The State Intellectual Property Office, Fujian Quality And Right Protection Service (Member) Unit, Fujian Integrity And Labor Advocate Unit, Quanzhou Industry And Commerce Credit Good Enterprise, Quanzhou Creditable Unit, Quanzhou LED Technology Research Center and Quanzhou LED Industry Technology Innovation Strategy Alliance Chairman Unit.

Our company always implements our development target and insists on the tenet of "customers are the growing power source". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.

Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems.
