New Digital Audio Amplifier (FP10000Q) , Power Amplifier, Audio Amplifier, PRO AMP, Line Array Amplifier
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Money Gram |
| Prod Model: |
FP10000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Colour: |
Black |
| Type: |
Professional Amplifier |
| Usage: |
Outdoor |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Function: |
Post Amplifier |
| Sound Channel: |
4.1 |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
AB |
Product Description
Digital audio Amplifier:
1.8ohm Stereo Power(RMS): 1300WX4
2.4ohm Stereo Power(RMS): 2100WX4
3.2ohm Stereo Power(RMS): 2500WX4Features:
1: FP series is uses new FM-wide regulator would be get more power technology. It is a small size ,low weight and high efficiency ,high power and high reliability. Both mobile and fixed installation performance are the best choice for you .2: Fidelity output:High-efficiency amplifier output circuit , small size ,high power density,Hifi-lever tone .3: Perfect protection system:It has full function protection, it includes power soft start,overload and short circuit,DC, overheating ,UHF, clipping limiter function,especially without output relay protection, it has reflected the rapid,accurate, is the relay cant not be compared.
| Model | FP10000Q |
| Output Power | 20-20kHz, 1W with 1 khz |
| 8Ω Stereo Power(RMS) | 1300WX4 |
| 4Ω Stereo Power(RMS) | 2100WX4 |
| 2Ω Stereo Power(RMS) | 2500WX4 |
| 8Ω Bridged Power(RMS) | 4200WX2 |
| 4Ω Bridged Power(RMS) | 5000WX2 |
| Frequency Response(+o/-0.3dB, 1W/8Ω ) | 20 Hz - 34 kHz |
| THD 20 Hz - 20 kHz for 1 W | < 0.1% |
| Signal-to-Noise Ratio | > 112 dBA |
| Channel separation (Crosstalk) at 1 kHz | > 70 dB |
| Input Connectors (per channel) | 3-pin XLR, electronically balanced |
| Output Connectors (per channel) | Binding Posts 2-pole |
| Class | TD |
| TourClass Protection | ACL, IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input |
| Operating voltage, 230 V / 115 V nominal | 130-265 V / 65-135 V selectable |
| Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
| Input impedance | 20 kOhm |
| Level adjustment (per ch. ) | Front-panel potentiometer, 31 position detented from -inf to 0 dB |
| Dimensions (W× H× D) | 483× 88× 396mm |
| Packing dimension | 560× 180× 500mm |
| Net weight(kg) | 15 |
| Gross weight(kg) | 18 |
