| Prod Model: |
CFQ |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Viscosity: |
1-500 |
| Housing Material: |
304, 316L, CS |
| Design Pressure: |
0.6, 1.0MPa |
| Filter Cartridge Length: |
10, 20, 30, 40,60 |
| Usage: |
Chemical Industry |
| Motive Force: |
Pressure |
| Type: |
Liquid Cartridge Filter |
| Certification: |
ISO9000 |
Product Description
CF series Cartridge Filter (CF filter for short), with filter cartridges as filter elements, is capable of liquid precision filtration. It can remove tiny impurities and bacterium. CF filter has the advantages of high filtration rating and high dirt holding capacity.It has various high performance filter cartridges developed by LIVIC, and can meet various conventional and special filtering requirements. The following 4 sub-series are available:
CFK Series filter, is an economical filter, it has tri-clamp lid and is easy to operate, suitable for conventional filtration of low flowrate and low pressure.
Series CFV filter, is a type of high-end filter, competent to the most demanding applications. It's reliable and durable with flange sealing lid and has quick open design and assistant davit.
Series CFM filter, with MaxSEP series cartridge, especially designed for applications of high flowrate, high filtration rating and high dirt holding capacity. It has both horizontal and vertical design, high flowrate, compact structure and easy cartridge replacement. Other design features are the same as the CFV Series.
Main Specification
Optional filter cartridge: MaxSEP, PolySEP, PesSEP, PtSEP, MeshSEP, FiberSEP, PorSEP, V-SEP, FineSEP, MicroSEP
Rating (μm): 0.05-200
Cartridge size (inch): 10,20,30,40
Capacity of cartridge: 1-200
Housing Material: 304,316L,CS
Applicable Viscosity (cp): 1-500
Design pressure (MPa): 0.6, 1.0
Applicable industries and liquid
Applicable industries: Fine chemicals, water treatment systems, plup and paper, automobile manufacturing, petro-chemical, machining, coatings, electronics etc.
Applicable liquids: Wide applicability, all liquids contained micro-impurities.
Filtration function: Remove small particles, purify liquids, protection of critical equipment
Filtration type: One-time intercept filtering, the filter bag need to be replaced manually regularly
Packaging & Delivery
Packaging Details:Delivery Detail:
| Plywood Case: professinal packing to ensure no break down of the products during long distance delivery. |
| About 40 days, according to the order quantity |
Specifications
Pleated Cartridge Filter
1.For high precision filtration
2.High filtration ratings
3. Meet different needs for flow capabili
CF Cartridge Filter
CF Series Cartridge Filter (CF Filter for short), with filter cartridges as filter elements, is capable of liquid precision filtration. It can remove tiny impurities and bacterium. CF filter has the advantages of high filtration rating and high dirt holding capacity.It has various high performance filter cartridges developed by LIVIC, and can meet various conventional and special filtering requirements. The following 4 sub-series are available:
K Series CF filter, is an economical filter, it has tri-clamp lid and is easy to operate, suitable for conventional filtration of low flowrate and low pressure.
V Series CF filter, is a type of high-end filter, competent to the most demanding applications. It's reliable and durable with flange sealing lid and has quick open design and assistant davit.
M Series CF filter, with MaxSEP series cartridge, especially designed for applications of high flowrate, high filtration rating and high dirt holding capacity. It has both horizontal and vertical design, high flowrate, compact structure and easy cartridge replacement. Other design features are the same as the V series.
P Series CF filter, with PowerSEP series cartridge, especially designed for applications of high flowrate, high filtration rating and high dirt holding capacity. Its design features are the same as the M series.
