| Prod Model: |
SGD0410 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LCM Type: |
Stn,Positive, Transflective |
| LED Backlight: |
Green |
| DOT Format: |
0.31X0.31mm |
| Outline Dimension: |
78.0X70.0X13.5mm |
| View Area: |
65X62mm |
| Pixel: |
128 X 64 Dots |
| Controller COB: |
S6b0724 or Equivalent; Vdd 3.3V |
| Operation Temp.: |
- 20 C°to +70c° |
| Storage Temp.: |
- 30c°to + 80c° |
| Type: |
STN |
| Application: |
Mobile Phone |
| Aspect Ratio: |
16:10 |
| Widescreen: |
Not Widescreen |
| Feature: |
3D Display |
| Optimum Resolution: |
1680x1050 |
| Screen Size: |
≤17" |
| Interface Type: |
AV |
| Response Time: |
10ms |
| 3D: |
3D |
Product Description
Packaging & Delivery
| Packaging Details: | Inner foam box and out export carton |
|---|
| Delivery Detail: | 30-45 days after down payment with PO |
|---|
Specifications
- STN 128X64 Standard LCD Module
- Short Time Delivery Lead Time(10 DAYS)
- Stable High Quality
- LED Backlight
| LCM type: | STN,positive, transflective | Pixel: | 128 X 64 dots |
| LED backlight: | green | Controller COB: | S6B0724 OR EQUIVALENT; VDD 3.3V |
| Dot format: | 0.31x0.31mm | Operation temp.: | - 20 C°TO +70C° |
| Out dimension: | 78.0X70.0X13.5mm | Storage temp.: | - 30C°TO + 80C° |
| View area: | 65x62mm | | |
By the way: All our LCM display type, backlight color, assembly way of the LCM can be customized per request, involvement engineering support and total display solution.
Main clients:
Application: Auto electronics,3D&Shutter,Meters&Instrument,Telecommunication,Domestic electrical appliance, Fuel dispensers, Office equipment, Medical &health equipment, Business related facility, Education electronics
Suzhou Tomy Optronics Co., Ltd (TOMY) established in 2010, specializes in the design, development, production, sales and services of state-of-the-art liquid crystal display modules and related electronic products.
TOMY mainly produces thousandds of types of standard or customized TN, STN, color STN and TFT-LCM products. Application of our products include: Instruments, office equipments, messages, telecommunications, home appliances as well as automotives.
Our TOMY Optronics Is a professional LCD manufacturer with 19 years' Experience. Our production equipment and technology brought in from Japan. TOMY is equipped with a young and highly qualified management and technology team dominated by postgraduate students. This guarantees that TOMY will take the lead in its industry.
TOMY has passed ISO 9001, ISO 14001, TS 16949 certifications as well as RoHS and REACH certification. TOMY is confident and determined to overcome endless challenges to become the best small-to medium sized display customization company.
