| Prod Model: |
Sanway LA-208 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency Response (±3 Db): |
65 Hz - 20 kHz |
| Amplification Type: |
Passive |
| Usage: |
Karaoke |
| Structure: |
Closed Enclosure |
| SNR: |
81-90dB |
| Speaker Material: |
Plywood |
Product Description
LA-208 Dual 8" Neodymium Driver Compact Line Array Speaker System
The LA-208 is a small two way line array enclosure designed to bring line array performance benefits to a variety of small and medium scale applications. It meets the need for a versatile, scalable system that can be flown or ground stacked for corporate events, theatres, indoor and outdoor venues. It is also suitable as a delay system for large scale outdoor sound reinforcement.
Following the constant directivity horn design philosophy, The LA-208 combines line array principles with innovative horn loading techniques to produce a next generation, small line array with maximum dynamic impact. Sanway recommends 4PCS LA-208 combination with 1PC LA-208B for extending low frequency.
Key Feature
1>. 2-way Bi-AMP Line Array system
2>. Dual 8 inch Neodymium woofer, dual 2 inch Neodymium Tweeter.
3>. Supported with a full range of flying accessories. Proprietary rigging system.
4>. For portable or permanent installation.
6>. Lightweight for easy touring or handling.
Applications
1>. Arenas
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement
Specifications:
| LA-208 |
| Frequency Response (±3 dB) | 65 Hz - 20 kHz |
| Sensitivity (1w/1m) | 98 dB SPL |
| Long-term SPL | 126 dB |
| Maximum SPL | 132 dB |
| Crossover | 2.5Khz |
| Nominal Impedance | LF 16 ohms; HF 16 ohms |
| Power rated(rms) | LF 380 watts; HF 60 watts |
| Peak Power handling | LF 760 watts; HF 120 watts |
| Dimensions (H x W x D) | 265 mm x 550 mm x 375 mm |
| Enclosure Material | 18mm high intensity plywood |
| Surface Finished | Textured black paint |
| Grille | Acoustic foam on perforated steel grille |
| Net weight | 19.8 kg |
| Low Frequency Driver | 2×8" high effeciency Neodymium |
| High Frequency Driver | 2×2" high effeciency Neodymium |
| Input Connectors | Neutrik NL4MPX2 |
LA-208Dual 15" Line Array Subwoofer Specification
| LA-208B Dual 15" Line Array Subwoofer |
| Frequency Response (±3 dB) | 30 Hz - 300Hz |
| Sensitivity (1w/1m) | 103 dB SPL |
| Long-term SPL | 132dB |
| Maximum SPL | 143 dB |
| Nominal Impedance | 4 ohms |
| Power rated(rms) | 1000 watts |
| Peak Power handling | 2000 watts |
| Dimensions (H x W x D) | 620mm×5500mm×750mm |
| Enclosure Material | 18mm high intensity plywood |
| Surface Finished | Textured black paint |
| Grille | Acoustic foam on perforated steel grille |
| Net weight | 55 kg |
| Low Frequency Driver | 2x15" ferrite woofer |
