| Prod Model: |
FCS 966 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Dual 30 Band Equalizer |
| Noise: |
<95dB |
| Application: |
Commercial |
| Certification: |
RoHS |
| THD: |
<0.005% |
Product Description
Karaoke Equalizer Audio, Graphic Equaliser Universal Equalizer (FCS 966)
The FCS966 is a high performance, low cost graphic EQ, featuring 30 ISO bands, each with 15dB gain. The filters have constant Q for improved efficiency, with a centre detent filter bypass at 0dB. The FCS966 also has separate HF and LF contour filters to adjust overall sound balance without having to adjust a detailed room or loudspeaker response, along with a sweepable high pass filter selectable from OFF to 250Hz.
*Balanced XLR, 1/4" jack and Phoenix/Combicon screw terminal analogue I/O
*Long-throw 45mm faders
*Bypass switch
*LF shelving filter provides +/-6dB gain @ 50Hz
*HF shelving filter provides +/-6dB gain @ 14kHz
*Main gain control from -∞ To +10dB
*8-segment LED metering with clip indicator
*3U rack-mountable
Specifications:
| FCS 966 Equalizer |
| Input Impedance | 10kOhm, electronically balanced |
| Output Impedance | < 50kOhms, electronically balanced |
| Input/Output | XLR-type, 1/4" TRS jack and Phoenix/Combicon screw terminals |
| CMRR | > -40dB@1KHz |
| Maximum Input Level | > +20dBu |
| Maximum Output Level | > +20dBu into 600 Ohms |
| GAIN control | +10dB to - infinity |
| HP filter control | OUT to 250Hz @ 12dB/octave |
| LF contour | +/-6dB shelving @ 50Hz 6dB/octave |
| HF contour | +/-6dB shelving @ 14kHz 6db/octave |
| FREQUENCY bands | +/-15dB on ISO centres with a Q of 4 |
| Frequency Response | 5Hz to 45kHz +/-1dB |
| Noise | < -94dB 22Hz to 22kHz |
| Dynamic Range | > 115dB |
| Cross Talk | > -80dB @1kHz |
| Distortion | < 0.005%THD (80kHz measurement BW) 20Hz-20kHz |
| Dimensions | 19" x 5.25" x 7.1" (483mm x 134mm x 180mm) |
| Weight | 6.6lbs (3kgs), unpacked |
| AC Power | 115/230V AC, 50/60Hz, 30VA |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
We always keep and follow the principle to do business:
The same product, we win by the quality;
The same quality, we win by the price,
The same price, we win by the service.
We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.
Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
