Prod Model: |
P6 indoor |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
P6 Indoor LED Display: |
P6 |
Display Type: |
LED Video Display |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Scanning Mode: |
1/4 Scan |
Certification: |
CCC |
Pixel Configuration: |
1R,1G,1B |
Pixel Pitch: |
6mm |
Pixel Density: |
27,777 dots / m² |
Application: |
Shopping Guide |
IP Rating: |
IP43 |
System Operating Platform: |
WIN2000 |
Product Description
Product Description
Factory ==Over 10 years
Quality Control == CE, RoHS, FCC, IP65, ISO9001 ==100% testing before shipping.
Competitive Prices -
Good After Sale Services
OEM==On Time Delivery
DESCRIPTION
Led Display for indoor and outdoor with full/dual/single color.
Led Display for semi-outdoor with full/dual/single color.
P1.9/P2.5/P3/P4/P5/P6...indoor full color led display;
P6/P8/P10/P12/P12.5/P16/P20/P25...outdoor full color led display;
3. P4/P4.75/P7.62/P10 Indoor/outdoor/semi-outdoor single/dual color LED screen etc.
FEATURE
Competitive Prices: full automatic production line reduce labor and management costs
Light Weight: Aluminum cabinet saving fright costs and conveniently installing.
Stable Performance - over 24 hours aging time, Malfunction dot rate Less than 0.0001.
4. Best quality LED chip tube.
The GREE, SILAN, OPTO, EPISTAR assuring high brightness and long lifespan.
5. Supporting different formats of images and videos
Flash, WAV/MIDI, Videos from TV and other equipments.
6. Quality insured by CPIC and 3-year QA.
The technical parameters of P6 door full color led display
Type | Technical parameters |
Module | 1) Pixel pitch:6mm 2) Density:27777 dots/m2 3) Lamp origin:R:Epistar G/B: SILAN 4) Colors: 1R1G1B 5) Led specs:SMD3528 6) Module resolution:W32×H32 7) Best viewing distance:6~20m 8) Best view angle:H160,V110 9) Environment temperature:-40ºC ~ +85ºC 10) Working temperature: -20ºC ~ +50ºC 11) RH:≤10~90% 12) Module Weight :About 600g |
Power | 1) Working voltage: 220V±10% 2) Suitable voltage: DC5V 3) Average Power consumption:384W/m2 4) Largest power consumption: 542W/m2 |
Control system | 1) Host:p4-80G/512m or better 2) Operating system:WIN 98/ 2000/ NT/XP 3) Control mode:Wireless LED information distribution system 4) Graphic card:DVI 5) Media card:PCTV |
Main Parameters
| 1)Driving IC:MBI Led Driver 2)Scan mode:1/8S 3)Frame frequency:≥60 frame/s 4)Refresh rate:≥300 Hz 5)Grey scale levels/Color processing:4096levels,Process 16.7M colors 6)Full white brightness:≥1500cd/m2 7)Brightness' adjustment mode: 100 levels available 8)Video signals:PAL/NTSC 9)Video Input/Output:8/8 10)Control System:Nonlinear Edit Card+DVI Graphic card+ Control card+Optical fiber transmission (optional) 11)MTBF:≥10,000 hours 12)Life-span:100,000 hours 13)Flatness:Neighbor pixel≤0.5mm;Module joint gap<1mm ; 14)Uniformity:pixel light intensity,module brightness uniformity 15)Power switch:Auto Switch 16)Switch power supply load:5V/40A 17)Computer display mode:800×600;1024×768 18) Network cable transition distance: 100m Multi-mode optical fiber transition distance:500m Mono-mode optical fiber transition distance:20km |
Software | LED Regular display software(MDK) |
Protection | Moisture/dust/ Resistant, electrostatic prevention, shockproof, meanwhile, against over-current, short-circuit, over-voltage and low voltage |
Image performance | Text,WORD,all formats of pictures(BMP/JPG/GIF/PCX...),as well as(MPG /MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RMJ/ASF...) |
Brilliantopto Co., Limited Was founded in 2005, with a registered capital of 20.18 million Yuan, a workshop covering an area of 20000 square meters and independent living and production places. Our company is professional in the development and manufacture of LED display systems. Our company technology strength is among the front row in this area, with a vigorous team.
In March, 2011, our company independently researched and developed a full-color formal P16 LED display, which can completely replace the current market single color LED displays, being the perfect choice in the next line of LED display market. In June, 2011, after designing P10 optical modules, we ceremoniously rolled out P10 light module series, which can effectively enhance the efficacy by above 10% and can effectively avoid a screen phenomenon. In August, 2011, our company took the lead in Quanzhou LED industry technology innovation strategy alliance. As the President unit, our company set up "Quanzhou LED Technology Research Center", featuring the national quality supervision center. Our company has many experts and professors from Xiamen University Semiconductor Research Center, Fuzhou University and Beijing University Institute of Photoelectricity for our research center technology consultation to comprehensively promote Quanzhou LED industry. In November, 2011, relying on our strong technical research and development team, we made a new generation of international leading 3D display screens.
Through six years of unremitting efforts, our company has successively obtained such honorary titles as The State Ministry Of Small-Sized And Medium-Sized Enterprise Technology Innovation Fund Project Unit, Small-Sized And Medium-Sized Enterprise In Fujian Province Technology Innovation Fund Project Unit, ISO9001 International Quality Management System Authentication Enterprise, CCC China National Mandatory Product Certification Enterprise, CE Compulsory Product Certification Enterprise, FCC Anti-Radiation Product Authentication Enterprise, RoHS Lead-Free Environmental Protection Product Authentication Enterprise, IP65 Waterproof and Dustproof Product Authentication Enterprise, Chinese Optical Optoelectronic Industry Member Unit, National Taxpayer Service Work Outstanding Member Unit, Unit With 15 Independent Research And Development Patents Of The State Intellectual Property Office, Fujian Quality And Right Protection Service (Member) Unit, Fujian Integrity And Labor Advocate Unit, Quanzhou Industry And Commerce Credit Good Enterprise, Quanzhou Creditable Unit, Quanzhou LED Technology Research Center and Quanzhou LED Industry Technology Innovation Strategy Alliance Chairman Unit.
Our company always implements our development target and insists on the tenet of "customers are the growing power source". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.
Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems.
